Thoob Ua Haujlwm Crane

Thoob Ua Haujlwm Crane

Cov Hom Thoob Plaws Ua Haujlwm Cranes
a. Muab ob npaug rau Girder Laus Thoob Quav
Lub peev xwm:Feem ntau 5-50 tons, nrog spans txog 35 meters.

Nta:
Kev ua haujlwm hnyav-tsim rau kev siv cov haujlwm siab (piv txwv li, khib nyiab khib nyiab, tsuas).
Nruab nrog cov tshuab khaws cov tshuab rau cov khoom tswj zoo.
Piv txwv li: QD series ob-girder crane txhawb nqa tau muaj peev xwm txog 800 tons thiab siv nyob rau hauv cov chaw muaj kev puas tsuaj.

b. Ib Leeg-Girder Lob Cranes
Lub peev xwm:1-35.5 tons, haum rau lub teeb cov khoom siv.
Qhov Zoo:
Raug nqi-ua tau zoo thiab cog qoob loo, zoo tagnrho rau cov chaw me.
Tuaj yeem ua khub nrog cov hluav taws xob hoists (piv txwv li, cd \/ MD qauv) rau Cob cov haujlwm.

c. Monorail kob hoists
Lub peev xwm:80 KG-3.2 tons, siv rau cov khoom siv hauv zos tuav.
Cov Ntawv Thov:Feem ntau sib xyaw ua ke rau hauv cov kab ntau lawm rau cov khoom siv hmoov av.

• Muaj peev xwm: {5-800} \/ 50 tuj
• SPAN ntev: 4-35 m
• Lifting qhov siab: 3-50 m
• Ua Haujlwm: A4, A5, A6, A7
• Siv voltage: 220V ~ 690v, 50-60 hz, 3 pd
• Kev ua haujlwm ib puag ncig: {-25 degree -+50 degree, txheeb ze cov av noo tsawg dua lossis sib npaug rau 85%
• Crane Control hom: Hauv av tswj \/ chaw taws teeb tswj \/ Alarm

Ib lub thoob ua ntej tsawv crane (lossis cov thoob cov thoob txwv muaj ntau yam uas ua haujlwm zoo li cov khoom siv xuab zeb, nplej, xuab zeb, lossis khib nyiab. Hauv qab no yog kev tawg ntawm nws cov khoom loj:

1. Cov qauv tseem ceeb
a. Choj \/ Girder
Tib Girder: Lub Teeb-Ua Haujlwm, Them Nqi (Siv rau peev xwm txog ~ 20 tons).
Ob Chav Girder: Hnyav-Hnyam-Heev-Heev, Muaj Peev Xwm Muaj Peev Xwm (rau kev muaj peev xwm nce rau 50+ tons).
Cov khoom siv: feem ntau hlau (thawv-hom lossis truss tsim) rau kev ua haujlwm ntev.

b. Kawg Cov Tsheb Thauj (End Florry)
Nruab nrog cov log txav lub crane ua raws cov kev sib tw khiav.
Suav nrog tsav cov tshuab roj (rau kev txav mus los) thiab cov tshuab ntaus braking.
c. Ramway Beams & Ntsia
Txhawb nqa crane lub zog los ntawm qhov ntev ntawm cov chaw ua haujlwm.
Ua los ntawm high-zog steel los lis cov khoom siv tsis sib haum.

2. Lifting & Laus Alchanism
a. Hoist chav
Hluav taws xob Hoist: muaj nyob rau hauv lub teeb-zog cranes (piv txwv li, cd \/ md hoists).
HYDRAULIC HOAN: siv rau cov ntawv thov hnyav (piv txwv li, chaw nres nkoj).
Xws li xaim hlua \/ nruas lossis saw rau lifting.

3. Fais fab & Tswj Lub Nruab
a. Kev pab fais fab
Cov kab tuav (cov tshuab hluav taws xob): xa hluav taws xob rau lub crane.
Cable reels: siv rau txawb lossis sab nraum zoov cranes.
b. Tswjhwm system
Pendant Control: Handheld chaw taws teeb rau kev ua haujlwm hauv phau ntawv.
Xov Xwm Xov Xwm Kev Tswj Xyuas Chaw Taws Xob: Wireless ua haujlwm rau kev nyab xeeb thiab hloov tau.
Lub Tsev Kho Mob: Tus Neeg Teb Xov Tooj Cabin rau cov cranes hnyav cranes.
c. Txwv kev hloov pauv & sensors
Tiv thaiv kev tshaj lij, overwinding, lossis kev sib nraus.

4. Kev Nyab Xeeb & Kev Nyab Xeeb Cheebtsam
a. Braking System
Neeg kho neeg ua haujlwm nres (rau hoist \/ trolley) thiab brakes thaum muaj xwm ceev.
b. Buffers & Bumers
Nqus poob siab kawg ntawm qhov kawg ntawm kev khiav.

c. Teeb pom kev zoo & tswb
Lus ceeb toom teeb thiab cov tswb rau cov chaw muaj kev phom sij.
d. Lubrication system
Rho tawm lossis phau ntawv ntsuas rau cov log, zog, thiab cov kabmob.

5. Yeem Ntxiv-ons
Uas cev: Cov kev ntsuas thauj lub cev hnyav hauv lub sijhawm tiag tiag.
Anti-Sway Technology: steeilizes tus tuav thoob thaum txav.
Plustproof \/ tawg-pov thawj qauv: rau cov chaw muaj kev puas tsuaj (piv txwv li, thee tuav).

Daim duab kos

Thoob plaws overhead cranes (tseem hu uatuav cranes) yog tshwj xeeb nqa cov tshuab tsim los tuav cov ntaub ntawv loj. Lawv muab cov txiaj ntsig tshwj xeeb thiab siv thoob plaws kev lag luam.

Qhov Zoo Ntawm Cov Thoob Plaws Ua Haujlwm Cranes
✔ Kev ua haujlwm siab nyob hauv cov khoom siv
Kev thau khoom ceev \/ thauj khoom - Cov thoob Laws tuaj yeem tuaj yeem ceev scoop, nqa, nqa cov ntaub ntawv, txo cov ntaub ntawv ua haujlwm.
Caw tawm ua haujlwm - lub cev muaj zog khaws cia tso cai rau cov chaw taws teeb lossis chaw ua haujlwm ntawm kev tswj hwm, txhim kho kev ceev thiab thev naus laus zis.
Epatility hauv cov khoom siv
Tuaj yeem siv cov xoob xoob, granular, lossis hmoov xws li:
Coal, ore, gravel, xuab zeb
Grain, chiv, ntsev
Khib, seem hlau, ntoo chips
✔ Chaw-txuag & siab thauj khoom muaj peev xwm
Kev ua haujlwm ua haujlwm ua haujlwm, pub dawb rau lwm qhov chaw rau lwm yam haujlwm.
Hnyav-cov qauv-cov qauv ua haujlwm (Ob Chav Girder) tuaj yeem nqa mus rau 50+ tons, ua rau lawv zoo tagnrho rau kev tsuas thiab chaw nres nkoj.
Txo cov kev sib kis nrog & txau
Cov lauj kaub nrog nrog cov plua plav tsawg tsawg thiab cov khoom poob thaum hloov chaw.
Pab tau nyob rau hauv cov khoom noj ua khoom noj (grain, qab zib) thiab tshuaj lom neeg qhov twg paug yuav tsum zam.
✔ Dustability & Kev Txij Nkawm Me Nyuam
Ua nrog cov hnav-resistant steel rau cov khoom muaj abrasive (piv txwv li, thee, tawg).
Tsawg dua txav chaw piv rau conveyor nruab, txo qis.
✔ Kev Nyab Xeeb Kev Nyab Xeeb & Tswj cov yam ntxwv
Los tiv thaiv tshuab hluav taws xob tiv thaiv kev ua viav vias.
Kev tiv thaiv kev tiv thaiv thiab tus brakes kub ntxhov kom muaj kev nyab xeeb.
Tuaj yeem ua haujlwm ntawm cov chaw taws teeb tswj, txo tus neeg ua haujlwm raug rau thaj chaw muaj kev puas tsuaj.

Cov Kev Siv Cov Khoom Siv Ntawm Thoob Thoob Ua Haujlwm Cranes

🟢 Siv Txom Nyem Tswj & Recycling

Khib khib nyiab hauv cov nroj tsuag-rau-lub zog.

Seem hlau sorting nyob rau hauv cov chaw ua rov qab.

🟢 Tsuas & Kev Tsim Kho

Coal, ore, thiab sib sau ua ke hauv cov mines thiab chaw sib cav.

Xuab zeb thiab gravel thauj khoom rau cov chaw tsim khoom.

🟢 Kev Ua Liaj Ua Teb & Kev Ua Lag Luam

Grain & Chiv pab thauj hauv Silos thiab cov chaw cia khoom.

Qab zib, ntsev, thiab pub tua hauv cov zaub mov ntau lawm nroj tsuag.

Chaw nres nkoj & Logistics

Chaw thau khoom \/ thauj cov nkoj nrog cov khoom thauj khoom (piv txwv li, thee, nplej).

Kev tswj khoom lag luam Tshuag rau cov khoom siv raw cia.

🟢 steel & fathabry kev lag luam

Kev tuav txoj kev swb hauv hlau mills.

Seem hlau txav hauv cov hauv paus.

🟢 Cov Nroj Hluav Taws Xob

Coal tuav rau boilers.

Cov ntoo tshauv tshem tawm ntawm cov cub tawg.

1. Tsim & Engineering
Yuav tsum tau tsom xam cov tshuaj tiv thaiv: txiav txim siab load muaj peev xwm, ncua, rub qhov siab, thiab ib puag ncig ua haujlwm.

Cad qauv: Tsim 3D tsim thiab cov qauv tsim qauv (tsom xam kev nyuaj siab, deflection, thiab lwm yam).

Xaiv cov khoom siv: Xaiv cov khoom siv caming (feem ntau nrum hlau lossis hlau nplaum) rau cov tsiaj tseem ceeb, cov neeg ua haujlwm kawg, thiab hooks.

Kev cai tswjfwm kev ua raws: kom ntseeg tau tias tsim qauv raws cov qauv (ISO, DIN, pojniam, lossis ASME).

2. Qauv Ua & Pwm Npaj
Qauv Tsim: ntoo lossis hlau qauv yog tsim rau cas rau casting cov pwm.

Sandber npaj:

Siv cov ntawv cog xuab zeb lossis cov xuab zeb ntsuab rau cov khoom noj kab noj hniav.

Cores (rau cov ntu hollow) tau npaj cais.

3. Cov txheej txheem ua cas
Melting & Pouringing:

Hlau (piv txwv li, cov hlau steel, alloy hlau) tau melted nyob rau hauv lub cub tawg.

Molten hlau tau nchuav rau hauv cov pwm nyob rau hauv kev tswj hwm.

Txias & solidification: cia lub caming kom txias maj mam kom tsis txhob muaj kev tsis xws luag.

Shakout & ntxuav: tshem tawm cov xuab zeb, thiab ntxuav cov voos khaub ncaws (kev txhaj tshuaj blasting, sib tsoo).

4. Machining & Xov
Kev ntxhib machining: tshem tawm cov khoom siv ntau dhau (rooj voom, risers).

Precision Machining: CNC Machining rau qhov tseem ceeb ntev (cov kabmob cov kabmob, ntsia liaj qhov rooj).

Cov kev kho deg: Painting, GALVANIZING, lossis cov tshuaj tiv thaiv corrosion.

5. Fabrication ntawm Choj Girder & Xaus Cov Vev Xaib
Vuam \/ Sib Dhos:

Fabricate box girders lossis i-nqaj (yog hybrid tsim).

Weld \/ Bolt kawg Fladryges (nrog log rau kev txav).

Kev Tshawb Fawb Kub Kub Kub Kub (yog tias xav tau) los txo cov kev ntxhov siab uas muaj kev ntxhov siab.

6. Sib dhos ntawm Crane Cheebtsam
Hoist & Trolley Txhim Kho: Mount Hluav Taws Xob Hoist los Hlau Hlaws.

Rail & Rase SETUP: Kev nruabts CANE txuas rau cov qauv kev txhawb nqa.

Kev sib xyaw ua ke hluav taws xob: Hlau Motors, tswj hwm, txwv qhov chaw khawb av, thiab cov khoom siv nyab xeeb.

7. Kuaj & Tswjhwm Zoo
Kev tshuaj xyuas seem: xyuas kom paub tseeb rau ib qho kev tsim tawm.

Tsis yog-ua kev sim siab (NDT):

Ultrasonic, sib nqus partlele, lossis zas contetrant sim rau cov kab nrib pleb.

Kev Tshawb Xyuas:

Qhov ntsuas zoo li qub li qub: 125% ntawm lub peev xwm ntsuas.

Dynamic load Kev Xeem: 110% ntawm lub peev xwm ntsuas nrog kev txav.

Kev Ntsuas Ntsuas: Tshawb xyuas braking, nqa, thiab kev ua haujlwm taug kev.

8. Painting & Corrosion tiv thaiv
Thov phau ntawv qhia thiab corrosion-resistant xim.

Cov cim (peev xwm, muaj pes tsawg tus lej, lus ceeb toom) raws li tus qauv.

9. Ntim & Xa Tawm
Disassemble (yog tias xav tau) rau kev xa khoom.

Tiv thaiv cov khoom tseem ceeb hauv kev hloov pauv.

10. Txhim kho & commissioning (ntawm thaj chaw)
Rov ua dua rau cov neeg siv khoom.

Kev sib ncag zaum kawg thiab kev ntsuas hluav taws xob.

Tus neeg teb xov tooj kev cob qhia thiab twv.

Lub tuam txhab tau teeb tsa cov khoom siv tswj hwm kev txawj ntse platform, thiab tau teeb tsa 310 teev (teeb tsa) ntawm kev tuav thiab vuam hlau. Tom qab ua tiav ntawm txoj kev npaj, yuav muaj ntau tshaj 500 teev (teeb tsa), thiab cov khoom siv sib txuas lus yuav ncav cuag 95%. 32 VUAM txoj kab tau muab tso rau hauv kev siv, 50 tau npaj yuav tsum tau nruab, thiab kev siv lub tshuab ntawm cov kab ntawv tag nrho tau mus txog 85%.
