Gantry Crane A Ncej



Lub gantry crane ib lub thav duab yog ib hom crane siv los nqa thiab txav cov khoom hnyav hauv ib puag ncig kev lag luam, feem ntau pom muaj nyob rau sab nraum zoov xws li warehouses, chaw tsim kho, lossis chaw nres nkoj. Hom crane no yog tus cwj pwm los ntawm nws cov qauv, qhov twg ib leeg girder (kab kab rov tav) txhawb nqa crane lub trolley thiab hoist, uas yog siv los nqa thiab txo cov loads.

2.Lub crane nta ib leeg girder txhawb nqa los ntawm ob txhais ceg ntsug, tsim ib qho "A" thav duab.

Lub girder khiav raws sab saum toj ntawm lub crane thiab txhawb nqa lub hoist uas txav raws qhov ntev ntawm lub nqaj.gantry crane ib lub thav duab yog tsim los tswj cov khoom nruab nrab mus rau hnyav, feem ntau yog li ntawm 1 tuj mus rau 20 tons, nyob ntawm cov specifications.Lawv yog tsim rau ob qho tib si sab hauv tsev thiab sab nraum zoov daim ntaub ntawv, muab kev ua haujlwm siab hauv ib puag ncig xws li chaw cia khoom, chaw thau khoom, lossis cov kab sib dhos.Vim lawv cov qauv tsim yooj yim thiab sib dua piv rau ob chav girder gantry cranes, lawv feem ntau pheej yig dua thiab yooj yim los tswj.

3.Lub crane muaj qhov yooj yooj yim, nrog lub hoist thiab trolley system tso cai rau kev txav txav ntawm cov khoom thauj thoob plaws qhov dav.Ua rau cov xwm txheej nyuaj, cov cranes no tiv taus cov huab cua xws li nag lossis huab cua kub, ua rau lawv zoo meej rau kev siv sab nraum zoov. tuaj yeem hloov kho rau ntau yam kev siv, suav nrog kev ntxiv ntau hom hoist, tswj tshuab (chaw taws teeb lossis alarm), thiab cov yam ntxwv ntawm kev txav mus los (rail mounted lossis roj hmab-tuag).

Qhov hnyav (KG): 10000 kg

Video tawm-kev tshuaj xyuas: Muab

Machinery Test Report: Muab

Xim: Customized

Fais fab mov hom: Synchro kab, cable reels lossis generators

Spreader: Customized

Txoj kev tswj: wireless romote, pendent los yog cabin tswj

Ceeb toom Device: Muab

Cross-over Track Design: Muab

Hluav taws xob: Schnider, SIMENS lossis raws li kev thov

Lub cev muaj zog: Suav lub npe nrov

Wearing Parts: Random free wear parts



1.Main beam

1) Tsim:

Lub ntsiab nqaj yog tsim los ua lub teeb yuag tsis tau muaj zog, muab kev txhawb nqa tsim nyog thaum txo qhov hnyav ntawm crane kom txo nqi.

Lub thawv-hom kab teeb feem ntau siv vim tias lawv ua haujlwm zoo thiab muaj peev xwm tuav cov khoom hnyav yam tsis muaj deformation tseem ceeb.

I-beams (steel I-sections) kuj tseem siv tau rau hauv qee qhov qauv tsim, muab kev xaiv zoo rau cov nqi qis dua.

2) Ntev thiab Span:

Qhov ntev ntawm lub ntsiab beam txawv nyob ntawm seb qhov yuav tsum tau ncua ntawm crane. Lub nqaj ntev tso cai rau lub crane los npog thaj tsam loj dua, thaum lub nqaj luv dua yog qhov sib npaug thiab haum rau qhov chaw me me.

Kev ncua yog qhov kev ncua deb ntawm ob txhais ceg ntsug lossis kev txhawb nqa ntawm gantry crane.

Lifting System

1) Kev ua haujlwm ntawm Lifting System:

Lifting lub Load:

Tus neeg teb xov tooj txav lub hoist vertically siv cov kev tswj hwm. Lub hoist txoj hlua los yog saw cua nyob ib ncig ntawm lub nruas, tsa tus nuv thiab ib qho txuas nrog.

Tsiv lub Load Horizontal:

Thaum lub load yog nqa, lub trolley txav raws lub ntsiab nqaj thauj cov load horizontally hla lub crane qhov ncua. Lub trolley yog powered los ntawm cov motors mus txawv tebchaws, uas txav lub crane lub trolley raws lem.

Txo qhov Load:

Txhawm rau txo cov load, tus neeg teb xov tooj thim rov qab cov kev taw qhia ntawm lub hoist, tso cai rau txoj hlua los yog saw kom tsis txhob muaj zog thiab maj mam txo cov load rau hauv av los yog txoj hauj lwm xav tau.

2) Cov ntsiab lus ntawm Lifting System Cheebtsam:

Hoist: nce thiab txo qhov load.

Trolley: Txav lub hoist raws lub ntsiab nqaj.

Kev mus ncig Mechanism: Tsiv lub trolley horizontally.

Hook/Lifting Attachment: Txuas mus rau lub load.

Control System: Tswj cov hoist thiab trolley txav.

Kev nyab xeeb nta: suav nrog kev tiv thaiv overload, txwv cov keyboards, thiab nres thaum muaj xwm ceev.

3.Endlub tsheb

Lub luag haujlwm ntawm qhov kawg Carriage hauv Crane Kev Ua Haujlwm:

1) Kab rov tav txav:

Lub luag haujlwm tseem ceeb ntawm lub tsheb kawg yog txav tag nrho cov crane raws nws txoj kev. Lub log thiab tsav system ntawm lub tsheb kawg tso cai rau lub crane taug kev horizontally hla tag nrho qhov ntev ntawm qhov chaw ua haujlwm, muab lub nra hnyav rau qhov xav tau.

2) Load Distribution:

Cov tsheb thauj khoom kawg pab faib qhov hnyav ntawm lub crane thiab lub thauj khoom sib npaug thoob plaws lub crane tag nrho. Los ntawm kev txhawb nqa lub ntsiab girder, trolley, thiab hoist, cov tsheb thauj neeg kawg kom ntseeg tau tias lub crane ua haujlwm zoo thiab nyab xeeb, tiv thaiv kev ntxhov siab tsis zoo ntawm ib qho khoom.

3) Kev ruaj ntseg thiab kev nyab xeeb:

Qhov kawg carriage plays lub luag haujlwm tseem ceeb hauv kev tswj xyuas lub crane stability thaum lub sijhawm ua haujlwm. Nws pab tiv thaiv tipping lossis wobbling ntawm lub crane los ntawm kev muab kev txhawb nqa ntawm txhua qhov kawg ntawm lub ntsiab girder, ua kom muaj kev sib npaug ntawm kev nqa thiab kev thauj mus los.

4) Qhov chaw rau Loading / Unloading:

Qhov kawg carriage tso cai rau lub crane mus tso nws tus kheej nyob rau hauv pem hauv ntej ntawm ib tug load, pab txhawb nqa thiab unloading txheej txheem. Nws ua kom lub crane muaj kev txav mus los kom ncav cuag txhua qhov chaw hauv qhov chaw ua haujlwm, xws li warehouses, docks, lossis chaw tsim kho.

4.Crane mus ncig teb chaws mechanism

Nta thiab Kev Ua Haujlwm ntawm Crane Mus Ncig Mechanism:

1) Mobility:

Lub tshuab mus ncig ua si tso cai rau lub crane txav mus rau kab rov tav raws li txoj kev tsheb ciav hlau lossis kev taug kev, muab nws nkag mus rau ntau qhov chaw ntawm qhov chaw ua haujlwm.

Nws ua kom muaj kev thauj mus los ntawm cov khoom hnyav dhau mus ntev.

2) Precision txav:

Nrog rau qhov sib txawv ntawm kev tswj ceev, lub tshuab tuaj yeem ua haujlwm ntawm qhov nrawm nrawm rau qhov tseeb qhov chaw lossis nrawm nrawm rau kev thauj mus los sai.

3) Load Handling:

Lub tshuab yog tsim los tswj qhov hnyav ntawm lub crane, lub hoist, thiab cov load, kom ntseeg tau tias du thiab ruaj khov txav nyob rau hauv hnyav loads.

4) Kev nyab xeeb:

Kev suav nrog cov brakes, txwv cov keyboards, thiab cov yam ntxwv nres thaum muaj xwm ceev ua kom lub crane tuaj yeem ua haujlwm yam xyuam xim, txawm tias nyob rau hauv qhov xav tau ib puag ncig.

5) Durability:

Cov khoom ntawm cov txheej txheem mus txawv tebchaws yog tsim los ntawm cov ntaub ntawv zoo los tiv thaiv kev siv txuas ntxiv thiab raug rau ib puag ncig hnyav.

5.Trolley mus ncig teb chaws mechanism

1) Qhov zoo ntawm Trolley Traveling Mechanism:

Ua haujlwm du thiab meej: Nruab nrog cov motors siab heev thiab tsav rau kev tswj kev txav.

Durability: Cov khoom zoo zoo li lub log steel thiab cov ntawv qhia cov menyuam ua kom lub neej ua haujlwm ntev.

Cov yam ntxwv ntawm kev nyab xeeb: suav nrog cov brakes, txwv cov keyboards, thiab coj cov menyuam rau kev nyab xeeb thiab txhim khu kev qha.

Customizability: tuaj yeem tsim kom tau raws li cov peev txheej tshwj xeeb thiab kev ua haujlwm.

2) Kev txiav txim siab txog kev kho:

Lubrication: Tsis tu ncua lubrication ntawm lub log, bearings, thiab iav txo kev sib txhuam thiab hnav.

Kev tshuaj xyuas: Kev tshuaj xyuas lub sijhawm ntawm lub log, cov ntsia hlau, thiab cov kev txwv hloov kom ntseeg tau tias lub tshuab tseem nyob hauv qhov zoo.

Lub cev muaj zog thiab Gearbox: Kev kuaj xyuas tsis tu ncua ntawm lub cev muaj zog thiab gearbox rau cov cim ntawm hnav, overheating, los yog misalignment.

Ntxuav: Khaws cov ntsia hlau thiab cov khoom trolley kom tsis txhob muaj cov khib nyiab kom ua haujlwm zoo.

6.Crane log

Kev saib xyuas kev saib xyuas rau Crane Log:

1) Kev tshuaj xyuas:

Tsis tu ncua xyuas lub log rau hnav, tawg, lossis deformation. Kev hnav ntau dhau ntawm lub log los yog flange tuaj yeem ua rau muaj teeb meem kev ua haujlwm thiab derailment.

Tshawb xyuas cov cim qhia ntawm misalignment, uas tuaj yeem ua rau tsis sib xws ntawm cov log thiab cov ntsia hlau.

2) Lubrication:

Xyuas kom lub lubrication zoo ntawm lub log bearings kom txo qis kev sib txhuam thiab txo qhov kev pheej hmoo ntawm overheating lossis puas.

3) Kev sib tw:

Kev sib raug zoo ntawm cov log thiab cov tsheb ciav hlau yog qhov tseem ceeb rau kev txav mus los. Cov log tsis zoo tuaj yeem ua rau hnav ntau dhau ntawm ob lub log thiab cov ntsia hlau, ua rau ua tsis tiav ntxov.

4) Khoom siv:

Saib xyuas qhov nyuaj thiab qhov chaw ntawm lub log. Sij hawm dhau mus, qhov chaw dov tuaj yeem xav tau rov ua dua lossis hloov kho kom muaj txiaj ntsig zoo.

5) ail condition:

Tshawb xyuas cov ntsia hlau rau kev puas tsuaj lossis hnav, vim tias kev tsheb ciav hlau tsis zoo tuaj yeem ua kom lub log degradation thiab cuam tshuam rau crane stability.

7.Crane Hook

1) Khoom siv:

Crane hooks feem ntau yog ua los ntawm high-strength forged steel los yog hlau alloy, kom ntseeg tau tias durability thiab muaj peev xwm tiv taus siab thiab hnyav loads.

Cov khoom yog kub-kho kom muaj zog, toughness, thiab tsis kam hnav thiab deformation.

2) Tsim:

Hooks yog tsim los kom sib npaug ntawm cov khoom thauj thiab tiv thaiv kev puas tsuaj rau cov khoom nqa.

Cov qauv tsim ntau tshaj plaws yog qhov sib txuas ib leeg lossis ob chav sib txuas:

Tib Hook: Siv rau cov khoom sib dua.

Ob Chav Hook: Siv rau cov khoom hnyav dua, qhov twg zoo dua qhov sib npaug thiab kev faib tawm.

Tsav

Hom Motors nyob rau hauv lub gantry crane ib tug ncej:

1) Lifting Tsav:

Powers lub hoist los nqa thiab txo cov loads.

Tsim los rau siab torque thiab meej tswj.

Feem ntau txawm peem rau nrog ib tug sib txawv zaus tsav (VFD) tso cai rau du acceleration thiab deceleration, kev txhim kho load tswj.

2) Trolley Traveling Tsav:

Tsiv lub trolley horizontally raws lub ntsiab girder.

Yuav tsum tau ceev ceev thiab cov kev taw qhia tswj kom muab lub hoist saum toj no lub load los yog lo lus uas peb.

Feem ntau ua ke nrog lub gearbox rau torque multiplication.

3) Crane Traveling Tsav:

Tsav cov tsheb thauj khoom kawg, ua kom tag nrho cov crane txav mus raws txoj kev khiav lossis hauv av.

Nws tuaj yeem ua haujlwm hauv synchronization (ib lub cev muaj zog ntawm qhov kawg ntawm lub tsheb thauj khoom) rau kev sib npaug.

Nruab nrog brakes thiab VFDs rau kev pib du, nres, thiab kev tswj ceev.

.

Suab thiab lub teeb tswb system & txwv hloov

1) Lub suab thiab lub teeb tswb System nyob rau hauv gantry crane ib tug ncej

Lub suab thiab lub teeb ceeb toom ntawm lub gantry crane ib lub thav duab ua haujlwm yog qhov tseem ceeb ntawm kev nyab xeeb, ceeb toom rau cov neeg ua haujlwm thiab cov neeg ua haujlwm nyob ze rau crane txoj haujlwm thiab muaj peev xwm txaus ntshai. Nws ua kom muaj kev nyab xeeb ua haujlwm los ntawm kev muab cov lus ceeb toom pom thiab hnov ​​​​thaum lub sijhawm ua haujlwm tseem ceeb.

2) Txwv Hloov nyob rau hauv gantry crane ib tug ncej

Qhov kev txwv tsis pub hloov yog cov cuab yeej kev nyab xeeb tau nruab rau ntawm gantry crane ib lub thav duab los tiv thaiv kev txav ntau dhau ntawm crane, trolley, lossis hoist, uas tuaj yeem ua rau muaj xwm txheej lossis khoom puas tsuaj.

10. Cov khoom siv ruaj ntseg

1) Overload tiv thaiv ntaus ntawv

Lub Hom Phiaj: Tiv thaiv lub crane los ntawm kev nqa cov khoom uas tshaj nws txoj kev nyab xeeb Tiv thaiv lub crane los ntawm kev puas tsuaj. Tiv thaiv cov hlua hlau lossis cov saw tsis ua haujlwm.

2) Limit Switches

Lub Hom Phiaj: Nres crane txav thaum nws mus txog qhov txwv tsis pub dhau los tiv thaiv kev hla dhau.Cia li kev sib tsoo, derailment, thiab khoom puas tsuaj.

3) Nres Nres Khawm

Lub Hom Phiaj: Muab kev txiav fais fab tam sim ntawd kom nres tag nrho cov haujlwm crane thaum muaj xwm txheej ceev. Cov lus teb ceev ceev kom cov neeg ua haujlwm muaj kev nyab xeeb thiab tiv thaiv cov khoom puas.

4) Suab thiab teeb tswb System

Lub hom phiaj: ceeb toom cov neeg ua haujlwm rau kev txav mus los ntawm cranes thiab cov xwm txheej uas muaj kev phom sij.Txhim kho kev paub txog chaw ua haujlwm, tshwj xeeb tshaj yog nyob rau hauv qhov chaw nrov nrov.

5) Anti-Collision System

Lub Hom Phiaj: Tiv thaiv lub crane los ntawm kev sib tsoo nrog lwm cov cranes lossis cov khoom ntawm tib txoj kev khiav.Protect cranes, cargo, thiab cov qauv nyob ze.

6) Overload ceeb toom System

Lub hom phiaj: ceeb toom rau tus neeg teb xov tooj thaum lub sijhawm thauj khoom mus txog lub crane lub peev xwm siab tshaj plaws. ceeb toom cov neeg ua haujlwm ntxov, txo qhov kev pheej hmoo ntawm kev thauj khoom ntau dhau.

11.Control hom

1. Pendant Control (Wired Control)

Cov khoom siv tes tuav txuas nrog lub crane ntawm ib lub cable.Tus neeg teb xov tooj tswj cov crane los ntawm nias cov nyees khawm ntawm lub pendant. Yooj yim thiab siv tau zoo.Muaj kev tswj hwm yooj yim rau kev nqa, txo qis, thiab crane / trolley txav.

2. Chaw taws teeb tswj (Wireless Control)

Ua haujlwm ntawm lub tshuab xa hluav taws xob, xws li lub xov tooj txawb chaw taws teeb lossis lub joystick controller.Siv xov tooj cua zaus (RF) lossis infrared (IR) thev naus laus zis.Muaj kev tswj xyuas tag nrho ntawm crane los ntawm qhov deb.

Muaj peev xwm suav nrog cov yam ntxwv siab heev xws li kev hloov ceev thiab kev tswj ntau lub crane.

3. Cabin Control

Lub crane yog tswj los ntawm tus neeg teb xov tooj lub alarm txuas nrog lub crane qauv.Tshwj xeeb nrog joysticks, levers, los yog ib tug tswj vaj huam sib luag rau kev ua haujlwm crane.Tus neeg teb xov tooj muaj tag nrho cov saib ntawm qhov chaw ua hauj lwm los ntawm lub alarm.Suitable rau kev ua hauj lwm hnyav thiab loj-scale industrial daim ntaub ntawv.

4. Tsis siv neeg tswj (Programmed lossis Semi-Automatic Control)

Siv lub programmed tswj system rau semi-automatic lossis tag nrho tsis siv neeg crane ua haujlwm.Ntau zaus nrog sensors, PLCs (Programmable Logic Controllers), thiab cov software siab heev.Predefined txav thiab cov dej num tuaj yeem ua tiav.The crane tuaj yeem hloov mus rau cov tswv yim los ntawm cov sensors lossis ib puag ncig. tej yam kev mob.

5. Dual Tswj hom

Ua ke ob lossis ntau hom kev tswj hwm (xws li, pendant tswj thiab cov chaw taws teeb tswj). Cov neeg ua haujlwm tuaj yeem hloov pauv ntawm cov qauv raws li cov kev xav tau tshwj xeeb.Muab kev hloov pauv rau ntau yam haujlwm lossis ib puag ncig.

12. Daim duab

Main technical





1. Nqi-zoo

Kev nqis peev qis dua:

Siv ib lub ntsiab girder, xav tau cov khoom siv tsawg dua piv rau ob chav girder gantry cranes.

Txo Cov Nqi Kho Mob:

Kev tsim qauv yooj yim thiab cov khoom siv tsawg ua rau txo qis kev kho thiab kho cov nqi.

Economical Installation:

Yooj yim thiab nrawm dua rau nruab, txo cov nqi zog thiab kev teeb tsa.

2. Lub teeb hnyav tsim

Lower Tuag Lug:

Lub teeb yuag tsim txo cov load ntawm crane lub log thiab cov qauv.

Kev thauj mus los yooj yim dua:

Nws qhov hnyav dua tso cai rau kev thauj mus los yooj yim dua thiab pheej yig dua mus rau qhov chaw teeb tsa.

Txo cov kev xav tau ntawm lub hauv paus:

Tsim kom muaj kev ntxhov siab tsawg dua ntawm cov tsheb ciav hlau thiab cov hauv paus, feem ntau tshem tawm qhov xav tau ntawm cov txheej txheem kev txhim kho.

3. Kev siv ntau yam

Haum rau ntau yam kev lag luam, suav nrog:

Kev tsim khoom.

Lub tsev khaws khoom.

Kev tsim kho.

Logistics thiab shipping yards.

Muaj peev xwm tuav tau ntau hom kev thauj khoom, xws li cov khoom siv ntau, tshuab, thiab ntim khoom.

4. Qhov chaw ua haujlwm zoo

Compact Structure:

Yuav tsum muaj tsawg lub taub hau thiab chaw ua haujlwm piv rau ob chav girder gantry cranes.

Maximized siv qhov chaw:

Zoo tagnrho rau ib puag ncig uas muaj qhov chaw tsawg lossis qis dua qhov siab.

5. Kev ua haujlwm yooj yim

Yooj Yim Tswj Kev Xaiv:

Muaj nrog pendant tswj, chaw taws teeb tswj, los yog cabin tswj, muab kev ua haujlwm yooj yim.

Tus neeg siv-phooj ywg tsim:

Ncaj nraim rau kev khiav lag luam thiab haum rau cov neeg ua haujlwm ntawm ntau qib kev txawj.

Kev ua haujlwm du:

Advanced lub cev muaj zog thiab tsav tshuab xyuas kom meej thiab du crane txav.





1. Kev Lag Luam Kev Lag Luam

Lub hom phiaj:

Tsiv cov khoom siv raw, cov khoom, thiab cov khoom tiav hauv cov chaw tsim khoom.

Kev siv:

Chaw thau khoom thiab unloading tshuab.

Sib sau ua ke thiab tso qhov chaw thaum lub sijhawm tsim khoom.

Kev thauj khoom hauv chaw ua haujlwm.

2. Warehouse thiab cia

Lub hom phiaj:

Kev tswj cov khoom lag luam zoo hauv warehouses thiab chaw cia khoom.

Kev siv:

Kev thauj khoom thiab tshem tawm pallets, thawv, lossis ntim khoom.

Stacking thiab teeb tsa cov khoom muag.

Kev xa khoom mus rau thiab los ntawm cov tsheb thauj khoom.

3. Cov chaw tsim kho

Lub hom phiaj:

Pab hauv cov khoom tuav cov dej num ntawm kev tsim kho.

Kev siv:

Nqa cov khoom siv xws li steel beams, qhob blocks, thiab prefabricated Cheebtsam.

Txhawb kev sib dhos thiab erection txheej txheem rau kev tsim vaj tsev.

Tsiv cov cuab yeej thiab cov cuab yeej hla cov chaw tsim kho.

4. Logistics thiab Shipping Yards

Lub hom phiaj:

Ua kom yooj yim tuav cov khoom hauv freight thiab logistics hubs.

Kev siv:

Kev thauj khoom thiab thauj cov tsheb thauj khoom, tsheb ciav hlau, lossis nkoj.

Kev teeb tsa cov thawv ntim khoom lossis cov khoom siv hauv cov chaw sab nraum zoov.

Kev thauj cov khoom loj hauv cov chaw logistics.

5. Automotive kev lag luam

Lub hom phiaj:

Pab hauv kev tsim khoom, sib dhos, thiab kho tsheb.

Kev siv:

Tuav lub tsheb qhov chaw, lub cav, thiab cov ncej.

Muab cov khoom pov tseg thaum lub sijhawm sib dhos lub tsheb.

Kev thauj cov khoom seem lossis cov tsheb tiav hauv cov chaw tsim khoom.





1. Tsim theem: Txiav txim siab qhov tsis sib xws ntawm cov crane, xws li cov khoom ntsuas ntsuas, ncua thiab nqa qhov siab, raws li tus neeg siv khoom xav tau thiab ib puag ncig ua haujlwm. Ua kom paub meej cov qauv tsim, suav nrog cov nqaj loj, qhov kawg beam, crane, nqa mechanism, thiab lwm yam, kom ntseeg tau tias tus qauv tsim muaj raws li cov qauv kev nyab xeeb thiab kev siv. Xaiv cov ntaub ntawv tsim nyog raws li tus qauv tsim, feem ntau yog cov hlau muaj zog los xyuas kom muaj kev ruaj ntseg thiab ruaj khov ntawm cov qauv.

2. Kev tsim khoom theem: Npaj cov khoom siv raw thiab cov khoom raws li cov qauv tsim. Txiav, khoov thiab tsim cov hlau los npaj cov khoom siv xws li cov kab teeb tseem ceeb thiab cov kab hluav taws xob kawg. Weld ntau yam khoom thiab sib sau ua ke rau hauv ib qho qauv tsim. Cov kauj ruam no yuav tsum tau lav vuam zoo kom muaj zog thiab ruaj khov.

3. Machining: Machining cov khoom tseem ceeb xws li lub cev muaj zog, lub zog, cov kabmob, thiab lwm yam kom ntseeg tau tias lawv qhov loj thiab qhov tseeb raws li qhov yuav tsum tau ua. Anti-corrosion kev kho ntawm cov khoom, xws li tha xim thiab galvanizing, tsub kom lub durability thiab zoo nkauj ntawm cov khoom.

4. Kev teeb tsa hluav taws xob: Nruab cov khoom siv hluav taws xob xws li motors, controllers, switches, sensors and alarm systems. Txuas thiab xaim cables kom ntseeg tau tias kev ua haujlwm zoo ntawm cov hluav taws xob.

5. Kev sib dhos theem: Sib sau ua ke tag nrho cov khoom siv thiab cov tshuab tag nrho, txuas lub tshuab nqa nqa, trolley khiav mechanism thiab tswj qhov system. Ua ib qho kev tshuaj xyuas tag nrho ntawm cov crane sib dhos kom paub meej tias tag nrho cov khoom thiab cov tshuab ua haujlwm tau zoo, thiab ua qhov kev debugging ua ntej.

6. Kev sim theem: Ua qhov ntsuas qhov ntsuas qhov zoo li qub ntawm lub crane los xyuas cov qauv ntawm lub zog thiab ruaj khov. Ua qhov kev ntsuam xyuas dynamic ntawm lub crane, suav nrog kev ntsuas ntawm kev nqa, txav, nres thiab lwm yam haujlwm, kom ntseeg tau tias nws qhov kev ua tau zoo raws li cov qauv tsim. Tshawb xyuas cov haujlwm ntawm cov khoom siv kev nyab xeeb, xws li kev txwv kev hloov pauv, kev tiv thaiv overload, thiab lwm yam, kom ntseeg tau tias muaj kev nyab xeeb ntawm cov khoom siv thaum ua haujlwm.

7. Kev Tswj Xyuas Zoo: Ua kom muaj kev tswj xyuas zoo ntawm txhua qhov txuas hauv cov txheej txheem tsim khoom kom ua raws li cov qauv kev lag luam thiab cov neeg siv khoom. Sau ntau yam ntaub ntawv thiab kev soj ntsuam tau nyob rau hauv cov txheej txheem ntau lawm rau tom ntej traceability thiab tsom xam.

8. Kev xa khoom thiab kev teeb tsa: ntim thiab npaj cov crane ua tiav rau kev thauj mus los kom ntseeg tau tias nws tsis puas thaum lub sijhawm thauj mus los. Xa lub crane mus rau tus neeg siv khoom qhov chaw rau kev teeb tsa, thiab ua rau ntawm qhov chaw debugging thiab txais. Muab kev cob qhia kev ua haujlwm rau cov neeg siv khoom kom paub meej tias lawv paub siv thiab tu cov crane.

Rhiav saib:

Lub tuam txhab tau teeb tsa cov cuab yeej ntse tswj kev tswj hwm lub platform, thiab tau teeb tsa 310 teeb (teev) ntawm kev tuav thiab vuam robots. Tom qab ua tiav ntawm txoj kev npaj, yuav muaj ntau tshaj 500 teeb (sets), thiab cov khoom siv sib txuas yuav ncav cuag 95%. 32 welding kab tau muab tso rau hauv kev siv, 50 yog npaj rau nruab, thiab automation tus nqi ntawm tag nrho cov khoom kab tau mus txog 85%.
