Explosion Proof Overhead Traveling Crane

Lub Explosion yog dab tsi -Cov pov thawj Overhead Traveling Crane?

Kev tawg tawm - pov thawj overhead mus ncig ua si crane yog ib qho tshwj xeeb kev lag luam crane tsim los ua haujlwm nyab xeeb nyob rau hauv qhov chaw muaj kev phom sij uas muaj cov pa taws, vapors, combustible dusts, lossis ignitable fibers.

Lub hauv paus ntsiab lus tseem ceeb yog kev tiv thaiv ntawm ignition. Cov cranes no tau tsim los xyuas kom meej tias txhua qhov hluav taws xob hluav taws xob, arc, lossis qhov kub ntawm qhov chaw tsim tawm thaum lub sijhawm ua haujlwm ib txwm muaj lossis vim muaj qhov ua txhaum tsis tuaj yeem cuam tshuam qhov chaw nyob ib puag ncig.

Lawv tsis yog "pov thawj" tiv thaiv kev tawg los ntawm qhov chaw sab nraud, tab sis yog tsim los tiv thaiv kev tawg.



Yuav Ua Li Cas Lawv Tau Txais Kev Nyab Xeeb Kev Nyab Xeeb: Peb Txoj Kev Tseem Ceeb

Kev tawg- cov khoom pov thawj yog tsim los rau cov qauv tshwj xeeb (xws li NEC hauv Asmeskas lossis ATEX hauv Europe). Txoj kev tiv thaiv rau cov khoom siv crane feem ntau poob rau hauv peb pawg:

1. Kev tawg-Cov ntaub ntawv pov thawj (Qhov feem ntau txoj hauv kev rau cov khoom siv hluav taws xob)

Txoj kev no yog siv rau cov khoom uas tuaj yeem tsim cov nplaim taws, xws li lub cev muaj zog, tswj vaj huam sib luag, thiab cov thawv sib txuas.

Txoj Cai:Cov khoom siv hluav taws xob muaj nyob hauv qhov muaj zog heev, nplaim taws- nruj nruj.

Nws ua haujlwm li cas:Yog hais tias ib qho hluav taws xob sab hauv los yog tawg tshwm sim, lub thawv ntawv muaj zog txaus los ntim nws. Tsis tas li ntawd, cov pob qij txha ntawm lub cev thiab nws lub hau npog yog machined rau ib qho "txoj kev nplaim taws." Txoj kev no ua rau cov roj kub kub khiav tawm ntawm qhov tawg mus rau qhov kub thiab txias hauv qab qhov hluav taws kub ntawm qhov chaw sab nraud.

Visual Cue:Cov ntaub thaiv no feem ntau hnyav, cam khwb cia hlau (hlau lossis aluminium) lub thawv nrog qhov tseem ceeb, bolted flanges.

2. Intrinsic Safety (rau Control Circuits)

Txoj kev no yog siv rau qis - fais fab circuits xws li pendant tswj chaw nres tsheb, xov tooj cua receivers, thiab sensors.

Txoj Cai:Cov hluav taws xob hluav taws xob (tam sim no thiab qhov hluav taws xob) hauv qhov hluav taws xob tswj hluav taws xob yog txwv rau qib qis dhau los ua kom muaj lub txim hluav taws xob txaus los ua kom muaj hluav taws xob, txawm tias muaj teeb meem.

Nws ua haujlwm li cas:Ib qho tshwj xeeb "intrinsic security barrier" yog ntsia rau hauv qhov chaw nyab xeeb - thaj chaw tswj vaj huam sib luag. Qhov kev txwv no txwv lub zog pub rau cov cuab yeej teb hauv thaj chaw muaj kev phom sij.

3. Pressurization / Purging (tsawg dua rau tag nrho cov cranes, tab sis siv rau cov txee tswj)

Txoj Cai:Cov pa huv si, tsis muaj zog (xws li nitrogen lossis ntsuas cua) tau muab tso rau hauv qhov chaw kaw, tswj kom muaj lub siab zoo sab hauv kom tiv thaiv qhov cua nkag mus.

Nws ua haujlwm li cas:Lub kaw lus ua ntej "pururges" qhov chaw ntawm tej huab cua phem, ces tswj lub siab zoo tas li. Interlocks tiv thaiv lub hwj chim los ntawm kev siv kom txog thaum lub voj voog ntxuav kom tiav thiab tswj kom muaj zog.



Core Cheebtsam: Bearing, Gearbox, Tsav, Twj

Qhov chaw ntawm Keeb Kwm: Henan, Suav

Warranty: 1 Xyoo

Qhov hnyav (KG): 2000 kg

Video tawm -kev tshuaj xyuas: Muab

Machinery Test Report: Muab

Design: Ob chav beam

Efficiency: high efficiency

Kev khiav hauj lwm ceev: kev khiav hauj lwm ceev

Kev ruaj ntseg: Kev tiv thaiv - ua haujlwm viav vias

Xim: xaiv tau

Lub Zog: 110V / 220V / 230V / 380V / 440V, customized

Ntev: 7.5-31.5m

Ntawm no yog cov ncauj lus kom ntxaws txog cov ntsiab lus tseem ceeb ntawm kev tawg - pov thawj nyiaj siv ua haujlwm crane, piav qhia txog yuav ua li cas txhua qhov tshwj xeeb tsim los yog hloov kho rau kev ua haujlwm nyab xeeb hauv qhov chaw muaj kev phom sij.

Lub hauv paus ntsiab lus tseem ceeb yog qhov ntawdtxhua yam khoom uas muaj peev xwm ua tau ib lub txim, arc, los yog kub heev yuav tsum muaj los yog tiv thaivtiv thaiv ignition ntawm ib puag ncig cua.



1. Cov Qauv & Mechanical Cheebtsam

Cov no feem ntau zoo ib yam li tus qauv crane tab sis feem ntau ua rau tus qauv siab dua ntawm kev ruaj khov thiab ua tib zoo saib xyuas kom tsis txhob muaj teeb meem tshwm sim.

Choj Girder (s):Lub ntsiab kab kab rov tav uas txhawb nqa lub hoist thiab trolley. Txawm hais tias tsis yog "kev tawg- pov thawj" hauv kev txiav txim siab hluav taws xob, lawv tau tsim kom muaj zog thiab nruj kom txo qis deflection thiab kev co, uas tuaj yeem ua rau xoob ntawm kev sib txuas hluav taws xob.

End Trucks:Cov rooj sib txoos ntawm txhua qhov kawg ntawm tus choj uas lub tsev lub log rau lub crane txoj kev mus los ntev. Cov ntsiab lus tseem ceeb suav nrog:

Log:Ua los ntawm qib siab - steel zoo los tiv thaiv hnav thiab tawg los ntawm kev sib txhuam.

Bearings:Muab kaw thiab lubricated rau lub neej kom tsis txhob overheating.

Trolley Ncej:Lub thav duab uas txav tom qab hla tus choj girders thiab nqa lub hoist unit. Nws yuav tsum ruaj khov thiab xyuas kom muaj kev sib raug zoo ntawm lub hoist.

Hook Block & Hook:Feem ntau ua los ntawm qib siab -, forged alloy steel. Tus nuv nws tus kheej zoo ib yam li tus qauv nuv tab sis feem ntau nruab nrog akev ruaj ntseg latchkom tiv thaiv kom tsis txhob muaj kev sib tsoo. Qhov kev txhawj xeeb tseem ceeb yog siv cov ntaub ntawv uas yuav tsis cuam tshuam los ntawm kev cuam tshuam.

2. Tseem ceeb hluav taws xob & tawg-Cov khoom pov thawj

Qhov no yog qhov uas qhov sib txawv tseem ceeb nyob. Txhua yam khoom siv hluav taws xob yog qhov muaj peev xwm ignition thiab tau tsim tshwj xeeb.

a) Hoist Tsav

Txheem:Tus qauv TEFC (Tag nrho Cov Ntxuam Ntxuam Txias) lub cev muaj zog.

Explosion-Cov pov thawj:Nyob hauv ibhnyav-lub luag haujlwm, cam khwb cia hlau lossis aluminium enclosurenrog precisely machinednplaim taws txoj kevnyob rau hauv tag nrho cov pob qij txha (qhov twg lub hau raws li lub cev). Yog hais tias muaj qhov tshwm sim sab hauv, qhov tawg tau muaj nyob rau hauv lub qhov rooj, thiab cov pa roj tawm tau txias hauv qab qhov kub ntawm qhov hluav taws kub thaum lawv dhau los ntawm txoj kev nqaim.

b) Tsav Tsheb Tsav Tsheb (Bridge thiab Trolley)

Ua haujlwm zoo ib yam li lub hoist lub cev muaj zog tab sis rau lub crane txoj kev hla thiab hla -traverse txav. Lawv siv tib yamtawg-cov ntaub ntawv pov thawjtshuab.

c) Tswj vaj huam sib luag / hluav taws xob txee

Qhov no yog "lub hlwb" ntawm lub crane, muaj cov contactors, relays, variable zaus drives (VFDs), thiab terminal blocks -tag nrho cov uas muaj peev xwm tsim arcs thiab sparks.

Explosion-Proof Adaptation:Nyob hauv ib qho loj,nplaim taws- nruj, nrum hlau enclosurenrog bolted flange. Tag nrho cov conduit nkag yog kaw nrogtawg- pov thawj foobtiv thaiv cov pa roj los ntawm kev mus los ntawm cov kav dej mus rau hauv lub txee.



d) Chaw Tswj Xyuas (Yuav ua li cas lub crane ua haujlwm)

Pendant chaw nres tsheb (Push Button Pendant):

Txheem:Lub thawv yas lossis hlau dai nrog cov nyees khawm.

Explosion-Cov pov thawj: A hnyav, kaw cam khwb cia txhuas lossis tooj dag lub cev. Txhua lub laub- khawm yog kaw, roj- raus dej, lossis diaphragm- kaw lub tsev kom tiv thaiv cov hluav taws sab hauv los ntawm kev khiav tawm. Lub cable nkag yog kaw.

Xov tooj cua tswj chaw taws teeb:

Qhov no yog ib qho kev xaiv zoo thiab muaj kev nyab xeeb vim nws tso cai rau tus neeg teb xov tooj nyob ntawm qhov chaw nyab xeeb.

Covhandheld transmitteryog certifiedIntrinsically Safe (IS). Qhov no txhais tau tias nws cov khoom siv hluav taws xob sab hauv yog tsim los txwv cov hluav taws xob thiab thermal zog mus rau theem uas tsis muaj peev xwm ua rau hluav taws kub.

Covunit txais, mounted ntawm lub crane, yog nyob hauv ib qhotawg-cov ntaub ntawv pov thawj.

e) Braking Systems

Electromechanical Brakes:Siv los tuav thiab nres thaum muaj xwm ceev. Lub brake coil thiab ib qho kev hloov hauv sab hauv yog nyob hauv ib qhotawg-cov ntaub ntawv pov thawj.

Mechanical Brakes:Feem ntau tsis ua tiav -kev nyab xeeb (caij nplooj ntoos hlav- siv) hom. Lub hom phiaj yog los ntawm kev siv cov khoom siv tsis yog-tshuaj rau hauv ob sab phlu thiab xyuas kom lawv tsis txhob kub dhau thaum siv.

f) Limit Switches

Siv rau sab sauv - txwv hoisting thiab kawg - ntawm - mus txawv tebchaws rau choj thiab trolley txav. Lub caij hloov pauv (uas tsim lub txim) yog nyob rau hauv ibcompact tawg- pov thawj vaj tse.

g) Teeb pom kev zoo

Chaw Ua Haujlwm Teeb Teeb & Ceeb Toom Beacons:Cov qij (tam sim no yuav luag txhua zaus LED rau kev ua haujlwm txias) yog nyob hauv ib qhomuaj zog, tawg- pov thawj fixturenrog lub iav tuab los yog polycarbonate lo ntsiab muag kaw tiv thaiv lub gasket. Lub fixture yog tsim los kom muaj kev tawg yog tias lub teeb yuav tawg.

h) Hlau & Conduit

Kev xaim:Siv high-qib, siab- kub, thiab tshuaj lom neeg- tiv thaiv rwb thaiv tsev.

Conduit:Tag nrho cov xaim khiav los ntawm kev kaw, nruj steel conduit.

Conduit Seals: Qhov no yog qhov tseem ceeb ntawm kev nyab xeeb.Explosion-cov ntaub ntawv pov thawj raug teeb tsa nyob rau hauv lub kav dej:

Ntawm qhov nkag mus rau txhua qhov tawg -cov ntaub ntawv pov thawj.

Nyob ntawm ciam teb ntawm Chav Kawm I, Division 1 (Zone 1) thiab thaj chaw muaj kev phom sij tsawg dua lossis muaj kev nyab xeeb.

Cov ntsaws ruaj ruaj no tiv thaiv kev tawg los ntawm kev mus los ntawm cov kav dej los ntawm ib feem ntawm lub cev mus rau lwm qhov thiab tiv thaiv cov roj hluav taws xob los ntawm kev tsiv mus rau hauv cov tswj vaj huam sib luag.

3. Kev Nyab Xeeb & Cov Khoom Pab Koom Tes

Earthing / Grounding System: Tseem ceeb heev.Tag nrho cov qauv crane (choj, trolley, tsheb thauj khoom kawg) yuav tsum tau ua kom zoo thiab txuas nrog hauv av kom tiv thaiv kev tsim ntawmhluav taws xob zoo li qub, uas yog ib qho teeb meem loj ignition. Ib qho txhuam txhuam hauv av feem ntau yog siv rau ntawm txoj kev khiav kom paub meej kev sib cuag.

Cov cuab yeej ceeb toom:Horns thiab beacons yog, tsis muaj kev zam,tawg- pov thawj pov thawjqauv.

Anti-Kev Sib tsoo Systems:Sensors thiab tswj rau ntau lub cranes ntawm tib txoj kev khiav yog nyob rau hauv tawg - pov thawj los yog intrinsically ruaj ntseg enclosures.

Cov ntsiab lus cua sov:Rau cranes nyob rau hauv ib puag ncig txias, txhua qhov cua sov los tiv thaiv cov dej khov ntawm cov ntsia hlau yuav tsum yog ib qhotawg- pov thawjhom.

Sketch

Main technical





Qhov zoo ntawm Explosion-Cov pov thawj Overhead Traveling Cranes

Lub ntsiab kom zoo dua yog, unequivocally,kev nyab xeeb. Txawm li cas los xij, qhov txiaj ntsig hauv paus no txhais ua ntau yam kev ua haujlwm tseem ceeb thiab nyiaj txiag zoo rau cov lag luam ua haujlwm hauv qhov chaw muaj kev phom sij.

1. Qhov kawg kev nyab xeeb nyob rau hauv ib puag ncig txaus ntshai

Tiv thaiv kev puas tsuaj:Lawv tau tsim kho kom tshem tawm qhov kev pheej hmoo ntawm crane nws tus kheej yog qhov chaw ntawm qhov hluav taws kub los yog tawg. Qhov no tiv thaiv tib neeg lub neej, infrastructure, thiab ib puag ncig los ntawm kev puas tsuaj loj.

Risk Mitigation:Los ntawm kev tsim, lawv txo qhov kev pheej hmoo ua haujlwm loj tshaj plaws hauv thaj chaw uas muaj cov cua kub hnyiab, muab kev thaj yeeb nyab xeeb ntawm lub siab thiab qhov chaw ua haujlwm muaj kev nyab xeeb dua.

2. Kev Ua Raws Cai thiab Kev Tiv Thaiv Kev Cai

Yuav Tsum Tau Ua:Hauv ntau lub tebchaws, kev siv cov cuab yeej txheem hauv cov chaw muaj kev phom sij yog qhov tsis raug cai. Cov cranes no tau tsim kom ua raws li cov qauv thoob ntiaj teb nruj (xws li NEC, OSHA, ATEX, IECEx).

Avoids Liability:Siv cov ntawv pov thawj tawg- cov ntaub ntawv pov thawj crane tiv thaiv lub tuam txhab los ntawm kev nplua loj, kev lav phib xaub, thiab kev pov hwm tsis raug cai thaum muaj xwm txheej.

3. Kev ua haujlwm tsis cuam tshuam thiab muaj kev ntseeg siab

Lub Hom Phiaj-Ua Tau Zoo:Lub Cheebtsam (lub cev muaj zog, hluav taws xob enclosures, thiab lwm yam) yog tsim los rau ib tug ntau dua tus qauv ntawm robustness thiab sealing tshaj tus qauv cranes. Qhov no ua rau lub tshuab ua kom muaj zog dua thiab txhim khu kev qha, txawm tias nyob rau hauv corrosive lossis xav tau kev lag luam ib puag ncig.

Txo Downtime:Lawv cov kev tsim kho muaj zog feem ntau ua rau lub sijhawm ntev dua ntawm kev ua tsis tiav (MTBF), txo qis qis qis uas tuaj yeem nres tag nrho cov kab ntau lawm lossis cov txheej txheem.

4. Ntev-Cov Nqi Them Sijhawm (Tag nrho Tus Nqi Ntawm Cov Tswv Cuab)
Thaum tus nqi pib yuav siab dua, qhov ntev - txuag lub sij hawm tseem ceeb:

Tiv thaiv Astronomical Losses:Tus nqi ntawm qhov xwm txheej tawg ib zaug - hais txog kev puas tsuaj ntawm cov khoom vaj khoom tsev, kev tsim khoom poob, thiab tus nqi tib neeg- yog qhov tsis txaus ntseeg siab tshaj tus nqi rau qhov tawg - pov thawj crane.

Insurance hwm:Cov tuam txhab uas siv cov cuab yeej muaj ntawv pov thawj zoo feem ntau tau txais txiaj ntsig los ntawm cov nqi pov hwm qis dua vim qhov kev pheej hmoo txo ​​qis.

Durability:Cov qib siab - cov khoom zoo feem ntau muaj lub neej ua haujlwm ntev dua, txo cov nqi hloov mus ntev -.

5. Kev ua haujlwm yooj yim thiab ua haujlwm tau zoo

Tswj Cov Khoom Siv Ua Haujlwm Ua Haujlwm:Lawv tso cai rau kev txav mus los ntawm cov khoom hnyav, cov khoom nyoos, thiab cov khoom tiavhauvthaj chaw muaj kev phom sij, uas yog qhov tseem ceeb rau kev tsim khoom. Yog tsis muaj lawv, kev tuav cov khoom yuav qeeb, tsis muaj txiaj ntsig, thiab muaj peev xwm txaus ntshai (xws li, siv kev siv tes ua haujlwm lossis cov txheej txheem improvised).

Advanced Control Options:Qhov muaj ntawv pov thawjtawg- pov thawj pendantsthiabintrinsically nyab xeeb xov tooj cua chaw taws teeb tswjtso cai rau cov neeg ua haujlwm tswj lub crane los ntawm qhov chaw nyab xeeb tshaj plaws thiab feem ntau ergonomic, ntxiv dag zog rau kev ua haujlwm thiab kev nyab xeeb.



Daim ntawv thov ntawm Explosion-Cov pov thawj Overhead Traveling Cranes

Cov cranes no yog qhov tsis tseem ceeb hauv txhua qhov kev lag luam uas muaj huab cua tawg tuaj yeem tshwm sim thaum lub sijhawm ua haujlwm ib txwm muaj lossis vim muaj qhov tsis txaus ntseeg. Lawv feem ntau raug cais los ntawm hom kev phom sij (Gas / Vapor lossis Dust).

Kev lag luam nrog Flammable Gases & Vapors (Class I / Zone 1 & 2)

Roj & Roj:

Refineries:Rau kev tuav cov catalysts, kev saib xyuas ntawm li qub / twj tso kua mis, thiab cov khoom siv dav dav siv nyob ib puag ncig cov kab ke thiab cov khoom ua haujlwm.

Offshore Platforms:Rau kev txav cov khoom siv thiab cov khoom siv ntawm lub platform uas muaj cov pa nkev vapors.

Petrochemical cog:Tuav cov tshuaj volatile intermediates thiab cov khoom.

Chemical & Pharmaceutical Manufacturing:

Hauv cov chaw ua haujlwm uas cov kuab tshuaj (xws li cawv, acetone, toluene) tau siv los yog qhov chaw tshuaj lom neeg tso tawm cov vapors flammable.

Cov chav sib tov, ntxuav lub reactor, thiab batch ua qhov chaw.

Paint & Coatings Facilities:

Paint Spray Booths:Qhov twg aerosolized xim thiab hnyav vapors tsim ib qho chaw tawg heev. Cranes yog siv los txav cov khoom hauv thiab tawm rau kev pleev xim.

Cov chav sib xyaw:Qhov twg cov kuab tshuaj thiab cov pigments sib xyaw.

Aerospace:

Xim Hangars:Rau painting loj aircraft fuselages.

Roj Cell Maintenance Bays:Nyob qhov twg muaj cov roj vapors seem.

Kev kho dej khib nyiab & Biogas cog:

Hauv thaj chaw uas decomposing organic teeb meem tsim methane thiab hydrogen sulfide gas.

Kev lag luam nrog Cov Plua Plav Hluav Taws Xob (Class II / Zone 21 & 22)

Nplej & Ua liaj ua teb:

Grain Elevators & Silos:Kev tuav cov nplej uas muaj plua plav hauv huab cua (nplej, pob kws, soy) yog qhov tawg heev.

Hmoov Mills:Thoob plaws hauv milling thiab ua kab.

Kev ua zaub mov:

Qab Zib & Starch Processing:Qhov twg zoo qab zib los yog hmoov txhuv nplej siab yog tsim.

Powdered Mis & Spice Facilities.

Woodworking & Biomass:

Sawmills & vaj huam sib luag cog:Qhov twg zoo ntoo hmoov av accumulates.

Biomass fais fab nroj tsuag:Rau tuav cov khoom siv roj xws li ntoo chips thiab pellets.

Hlau ua:

Aluminium tiav:Qhov twg nplua txhuas hmoov av yog tsim los ntawm kev sib tsoo los yog polishing.

Lwm yam hlau:Qee qhov magnesium, titanium, thiab hlau plua plav tuaj yeem ua rau tawg.

Coal Mining & Kev Ua Haujlwm:

Coal Handling Cog:Qhov twg thee hmoov av yog pervasive thiab tov nrog methane gas.



Kev tsim khoom ntawm QD Model Ob Chav Girder Choj Nyiaj Siv Ua Haujlwm Crane yog txheej txheem txheej txheem uas sib xyaw ua cov hlau hnyav, kev ua haujlwm zoo, kev sib dhos hluav taws xob, thiab kev tswj xyuas kom zoo.



Theem 1: Tsim & Engineering (Pre-Production)

Order Review & Technical Clarification:Cov kws tshaj lij tshuaj xyuas cov neeg siv khoom tshwj xeeb (muaj peev xwm, ncua, nqa qhov siab, chav ua haujlwm, hom tswj, thiab lwm yam).

Cov Qauv Tsim Nyog & Kev Xam Xaj:

Tus Qauv Tsim:Siv CAD software (piv txwv li, AutoCAD, SolidWorks), engineers tsim cov duab kos kom ntxaws rau txhua yam (girders, kawg tsheb thauj khoom, trolley ncej). Lub girder tsim yog qhov ntsuas ntsuas rau deflection, lub zog, thiab qaug zog lub neej.

Hluav taws xob tsim:Schematics rau lub hwj chim thiab tswj systems yog tsim, nrog rau cov nqi ntawm cov ntaub ntawv rau motors, panels, cables, thiab pendants.

Load Calculation & FEM Analysis:Niaj hnub nimno factories siv Finite Element Method (FEM) software los simulate kev ntxhov siab, lim, thiab deflection nyob rau hauv load, optimizing tus tsim ua ntej tej hlau txiav.



Theem 2: Raw Material Preparation & Processing

Khoom siv:Cov hlau phaj (feem ntau Q235B lossis Q345B rau cov qauv tseem ceeb), cov kab hluav taws xob (kab teeb, cov kab), cov ntsia hlau, thiab cov khoom yuav khoom (lub cev muaj zog, gearboxes, log, cov khoom siv hluav taws xob) yog los ntawm cov neeg muab ntawv pov thawj.

Cov khoom siv kuaj:Cov ntawv hlau xa tuaj feem ntau raug kuaj kom ua raws li qib kev qhia tshwj xeeb (kev kuaj ultrasonic yog ib txwm muaj).

Txiav & sib sau:

CNC txiav:Hlau daim hlau rau lub ntsiab girders raug txiav kom meej qhov ntev siv Computer Numerical Control (CNC) plasma lossis nplaim taws txiav tshuab. Qhov no ua kom cov neeg raug siab.

Drilling & Machining:Lub qhov rau kev sib txuas yog drilled siv hlau nplaum hauv paus xyaum los yog CNC machining chaw. Qhov kawg ntawm lub ntsiab girders yog machined los xyuas kom meej ib tug zoo meej, square haum nrog lub kawg tsheb.



Theem 3: Main Girder Fabrication (Cov Txheej Txheem Txheej Txheem)

Qhov no yog cov txheej txheem vuam tseem ceeb tshaj plaws.

Sib dhos & Jigging:Cov ntawv txiav (lub vev xaib thiab flange) tau muab tso rau hauv ib qho loj, nruj sib dhos jig. Lub jig no tuav txhua yam nyob rau hauv kev sib raug zoo thaum lub sij hawm vuam los tiv thaiv distortion thiab xyuas kom meej lub girder yog ncaj thiab cambered kom raug.

Vuam:Main girder welding yog ua los ntawm cov welder uas tau ntawv pov thawj siv Submerged Arc Vuam (SAW) ntev, lub ntsiab seams (uas muab kev nkag mus tob thiab siab - zoo welds) thiab Manual Hlau Arc Vuam (MMA) los yog Gas Hlau Arc Vuam (GMAW/MIG) rau me me txuas.

Cambering:Ib qho ua ntej - txhais tau hais tias nce toj camber (curvature) yog tsim rau hauv lub girder los tiv thaiv deflection nyob rau hauv lub load qhov hnyav. Qhov no yog ua tiav los ntawm jig tsim thiab vuam ib ntus.

NDT (Tsis yog -Kev kuaj kev puas tsuaj):Cov welds tseem ceeb raug tshuaj xyuas los ntawm cov neeg soj ntsuam zoo. Cov txheej txheem suav nrog:

Kev kuaj Ulasonic (UT):Txhawm rau kuaj xyuas qhov tsis zoo hauv cov welds.

Magnetic Particle Test (MT):Txhawm rau kuaj xyuas qhov tawg.

Fitting Attachment:Tom qab vuam, cov ntsia hlau rau lub trolley yog meticulously ua raws thiab welded los yog bolted mus rau sab saum toj ntawm cov tiav girders.



Theem 4: Xaus Tsheb & Trolley Ncej Fabrication

Fabrication:Cov tsheb thauj khoom kawg thiab trolley thav duab yog tsim los ntawm steel phaj, ua raws li cov txheej txheem zoo sib xws ntawm kev txiav, drilling, thiab vuam.

Machining:Cov cheeb tsam tseem ceeb, xws li cov kabmob vaj tse rau lub log thiab cov ncej tsav, yog machined rau siab kam rau ua kom muaj kev sib raug zoo thiab kev ua haujlwm zoo.

Kev sib dhos:Log, bearings, qag, tsav motors, thiab gearboxes tau sib sau ua ke rau hauv cov tsheb thauj khoom kawg. Ib yam yog ua rau lub trolley ncej.



Kauj Ruam 5: Kev Kho Hniav & Painting

Txhaj tshuaj Blasting:Txhua yam khoom siv tau muab tso rau hauv lub tshuab txhaj tshuaj blasting qhov siab - ceev steel abrasives ntxuav qhov chaw ntawm xeb, zeb nplai, thiab av. Qhov no tsim ib tug ntxhib, huv si saum npoo zoo tagnrho rau xim adhesion.

Priming:Tam sim ntawd tom qab blasting, high -zoo anti- xeb primer yog siv los tiv thaiv oxidation.

Kev kos duab:Lub topcoat yog siv, feem ntau raws li cov neeg siv khoom -cov xim thiab thickness yuav tsum tau. Qhov no feem ntau yog ua los ntawm kev siv tshuaj tsuag pleev xim rau kev ua tiav.



Theem 6: General Assembly & Hluav Taws Xob Installation

Ua ntej-Assembly:Lub ntsiab girders txuas nrog rau cov tsheb thauj khoom kawg los ua tus choj tiav. Lub trolley yog muab tso rau ntawm tus choj rails. Tag nrho cov qauv raug kuaj xyuas rau squareness thiab qhov tseeb.

Mechanical Installation:Lub hoist unit (QD-hom hoist) yog ntsia rau ntawm lub trolley ncej. Tag nrho cov tsav tsheb txuas nrog.

Kev teeb tsa hluav taws xob:Electricians xaim tag nrho cov crane:

Nruab lub ntsiab vaj huam sib luag thiab lub thawv tiv thaiv ntawm tus choj.

Khiav cables raws tus choj mus rau lub trolley thiab cov tsheb thauj khoom kawg.

Nruab lub festoon system los yog tus neeg xyuas pib bar rau lub hwj chim sau.

Nruab cov kev txwv txwv, cov khoom siv kev nyab xeeb, thiab teeb ceeb toom.

Txuas lub pendant tswj lossis ntsuas lub xov tooj cua chaw taws teeb tswj.



Theem 7: Kev Xeem & Kev Tshuaj Xyuas (Lub Hoobkas Txais Kev Xeem - FAT)

Qhov no yog ib kauj ruam yuav tsum tau ua ntej dismantling rau cov khoom xa tuaj.

Tsis muaj-Load Test:Lub crane yog ua haujlwm yam tsis muaj load. Tag nrho cov haujlwm raug kuaj: choj mus ncig, trolley mus ncig, hoisting nce thiab nqis. Kev txwv, nres, thiab tswj tau raug kuaj xyuas.

Static Load Test:Kev ntsuas ntsuas ntawm 125% ntawm lub peev xwm ntsuas yog nqa tawm hauv av (feem ntau nrog ntsuas qhov hnyav lossis cov hnab ntim dej ntsuas). Lub crane tau tuav rau 10+ feeb los xyuas seb puas muaj qhov deformation, thiab cov brakes raug kuaj xyuas kom muaj peev xwm tuav tau.

Dynamic Load Test:Ib qho kev ntsuas ntawm 110% ntawm lub peev xwm ntsuas yog nqa thiab muab tso rau hauv txhua qhov kev txav: mus ncig, trolleying, thiab hoisting. Qhov no kuaj cov kev ua haujlwm thiab kev nyab xeeb hauv kev ntxhov siab.

Dimensional soj ntsuam:Qhov loj me (span, nqa qhov siab, thiab lwm yam) raug txheeb xyuas qhov kev txiav txim.

Cov ntaub ntawv:Tag nrho cov qhabnias xeem, daim ntawv pov thawj rau cov ntaub ntawv thiab welds, thiab cov khoom siv phau ntawv tau muab tso ua ke rau hauv ib daim ntawv xa tuaj zaum kawg rau cov neeg siv khoom.



Theem 8: Dismantling, ntim & Shipping

Dismantling:Lub crane tau ua tib zoo disassembled rau hauv cov laj thawj, shippable Cheebtsam (xws li, ob lub ntsiab girders, ob lub tsheb kawg, trolley unit, hoist, hluav taws xob panels, runway rails).

Ntim:Cov khoom xyaw yog ntim los tiv thaiv kev puas tsuaj thaum lub sij hawm thauj dej hiav txwv lossis av. Cov khoom siv feem ntau yog ntim rau ntawm cov ntoo crates. Cov khoom siv hluav taws xob yog ntim thiab khaws cia rau hauv rooj ntoo.

Shipping:Txhua qhov chaw raug cim rau kev txheeb xyuas yooj yim thiab qhov chaw reassembly. Tom qab ntawd lawv raug xa mus rau cov neeg siv khoom qhov chaw rau kev teeb tsa los ntawm cov chaw tsim khoom cov kws tshaj lij lossis cov neeg siv khoom tus kheej.

Rhiav saib:

Lub tuam txhab tau teeb tsa cov cuab yeej ntse tswj kev tswj hwm lub platform, thiab tau teeb tsa 310 teeb (teev) ntawm kev tuav thiab vuam robots. Tom qab ua tiav ntawm txoj kev npaj, yuav muaj ntau tshaj 500 teeb (sets), thiab cov khoom siv sib txuas sib txuas yuav ncav cuag 95% . 32 cov kab vuam tau muab tso rau hauv kev siv, 50 tau npaj los nruab, thiab automation tus nqi ntawm tag nrho cov khoom kab tau mus txog 85%.
