50T COJ COJ OB GIRDER ASEAD CRANE





Ib qho 50T Ob Chav Girder Nyiaj Siv Ua Haujlwm Crane yog lub luag haujlwm ua haujlwm hnyav tsim tau rau cov ntawv thov kev lag luam muaj peev xwm kev lag luam siab, meej thiab kav ntev. Hauv qab no yog nws cov yam ntxwv tseem ceeb, Cheebtsam, thiab cov ntawv thov raug:

Cov Nta Tseem Ceeb:
Lub peev xwm: 50 metric tons (tuaj yeem yog kho rau cov khoom ntim siab dua).

Ob chav tsim qauv girder: ob tus tsiaj loj muab cov zog txhim kho thiab ruaj khov piv rau ib leeg-girder cranes.

Ntsev ntev: Kho tau (feem ntau 10-35 meters, nyob ntawm cov kev cai ua haujlwm).

Lifting qhov siab: customizable (feem ntau 6-30 meters).

Lub Luag Haujlwm Chav: A5 (muaj pes tsawg) rau A6 (hnyav zog) rau kev siv ntau zaus hauv kev xav tau ib puag ncig.

Kev tswj hwm kev tswj hwm: Pendant tswj, Xov Xwm Chaw Taws Teeb Tswj, lossis Alarm-ua haujlwm.

Kev Nyab Xeeb Nta: Tshaj tawm kev tiv thaiv, txwv cov hloov chaw, nres nres, thiab kev sib cav sib ceg.





Kev Sib Piv: QD Ob Chav Girder vs. Tib Girder

Yam zoo	Ob Chav Girder	Ib Leeg Girder
Lub peev xwm	5 - 550+ tons	1-7 tons
Khab mov	Txog 35m +	Mus txog 15m
Nuv qhov siab	Siab dua	Qi dua
Tus nqi	Siab dua tus nqi	Ntau dua kev lag luam
Yam ruaj khov	Hnyav-Luag Haujlwm	Lub teeb rau nruab nrab-ua haujlwm



Cov Cheebtsam Tseem Ceeb: Cov kabmob, Gearbox, Tsav, Twj

Qhov chaw ntawm Keeb Kwm: Henan, Suav

Warranty: 1 xyoos

Qhov hnyav (kg): 2000 kg

Video tawm-soj ntsuam: muab

Kev Ntsuas Cov Lus Qhia: muab

Tsim: Ob Chav Beam

Effelliveness: High Efficiency

Kev khiav hauj lwm ceev: Kev ua haujlwm nrawm

STABILES: Anti-Viav Foos Ua Haujlwm

Xim: Yeem

Lub Hwj Chim Source: 110V \/ 220V \/ 230V \/ 380V \/ 480V \/ 440V, Mekas

Ntsev: 7. 5-31. 5m







Ib qho 50 nyhav ob npaug Girder Nyiaj Siv Ua Haujlwm Crane yog lub luag haujlwm uas muaj sia nyob zoo li cov nroj tsuag hlau, cov nkoj xa khoom, thiab cov chaw tsim khoom loj. Ntawm no yog nws cov tseem ceeb:

1. Choj Qauv
Girders Main (2 Nos.) - Thawj cov ris nraaj kab (thawv lossis hom truss) txhawb nqa lub nra tag nrho.

Kawg cov tsheb thauj khoom (2 nos.) - Cov thav duab steel nrog cov log uas cia cov crane txav mus raws txoj kev sib tw.

Cov kab teeb hla kev - muab cov kev ruaj ntseg tom ntej ntawm cov tsiaj.

2. Hoisting Txheej Txheem
Hoby lub zog - powers lub neej ua haujlwm (feem ntau AC lossis DC).

Cov hlua hlau & nruas - nqa thiab lowers lub nra (yuav suav nrog ntau yam ntog rau 50T muaj peev xwm).

Nqe kauj ruam thaiv - Hnyav-Ua Haujlwm Lifting nuv nrog Pulley System.

Braking System - Ua kom muaj kev nyab xeeb thauj khoom (Disc lossis nruas nres).

3. Trolley Txheej Txheem
Trolley ncej - txav cov kab rov tav nrog tus choj girders.

Trolley lub cev muaj zog & tsav - Pab taug kev hla kev mus ncig ua si.

Cov log & kev tsheb ciav hlau - cov lus qhia Trolley kev txav.



4. End Trucks & Redway System
Cov log (4 lossis ntau dua) - khiav ntawm Crane khiav Rails.

Buffers \/ Bumpers - nqus cov kev cuam tshuam ntawm kev txwv ncig.

Cov kab teeb khiav - txhawb nqa Crane lub zog (mounted ntawm kab ntawv lossis cov qauv hauv tsev).

5. Hluav taws xob system
Tswj Vaj Huam Sib Luag \/ Alarin \/ Pendant - Tus Neeg Teb Xov Tooj interface (xov tooj cua chaw taws teeb lossis chaw taws tsheb).

Festoon \/ Tus neeg coj tuav - fais fab thiab kos npe kis tau.

Txwv txoj kev hloov mus - tiv thaiv dhau ntawm kev tawm tsam ntawm hoist thiab trolley.








6. Cov kev nyab xeeb
Kev siv dag lim dej dag - tiv thaiv kev nqa dhau 50T muaj peev xwm.

Nres nres (E-Nres) - tam sim ntawd txiav lub zog thaum muaj xwm txheej ceev.

Anti-kev sib tsoo system - siv hauv ntau cov Crane teeb.

Anemometer (yog nraum zoov) - Saib cov cua cua nrawm rau kev ua haujlwm nyab xeeb.





.

7. Ntxiv nta (yeem)
Crane nyhav nplai - kev ntsuas kev sib xyaw.

Hom tsis paub meej cov tsav tsheb (VFDs) - du acceleration \/ deceleration.

Sib nqus lossis tuav cov ntawv txuas ntxiv - rau kev nqa khoom tshwj xeeb.





50T Ob Chav Girder Nyiaj Siv Ua Haujlwm Crane yog tsim nrog kev nyab xeeb thiab txhim kho cov qauv hauv European (En 13001, FEM, thiab lwm tus). Hauv qab no yog qhov kev nyab xeeb tseem ceeb feem ntau suav nrog:



1. Thauj cov khoom siv lim
Tshaj dhau kev hloov pauv - tiv thaiv kev ua haujlwm crane yog tias lub nra hnyav tshaj lub peev xwm ntsuas.

Ntsaws ntawm tes \/ uas System - Saib xyuas cov thauj khoom hauv lub sijhawm tiag tiag los tiv thaiv kev tshaj lij.

2. Qhov kawg txwv hloov
Hoisting sepl \/ qis txwv hloov - nres lub hoist thaum tus nuv mus txog qhov siab tshaj lossis tsawg kawg yog qhov siab muaj kev nyab xeeb.

Trolley & Choj Ncig Tebchaws Txwv Khuam - txwv tsis pub CRANE los ntawm kev hla dhau ntawm qhov kawg ntawm kev khiav.

3. Tso Tawm Thaum Muaj Xwm Ceev (E-Nres)
Thawb Ncaws Pob Thawm Ceev - ntsia rau ntawm Pendant Tswj lossis Alarm rau kev kaw tam sim hauv kev kub ntxhov.

4. Anti-kev sib tsoo
Laser \/ ultrasonic sensors - pom cov nyom lossis lwm yam cranes los tiv thaiv kev sib tsoo (siv hauv ntau lub tshuab-crane).

RFID \/ ZONING TSHUAB - kom ntseeg tau cov cheeb tsam ua haujlwm zoo hauv ib puag ncig ib puag ncig.

5. Braking tshuab
Ua tsis tiav brakes (neeg kho tshuab & electromagnetic) - cia li koom tes thaum muaj lub zog tsis ua haujlwm.

Hoist tuav nres - tiv thaiv tsis tau txais kev txo qis ntawm lub nra.

6. Hluav taws xob kev nyab xeeb Cheebtsam
Undervoltage tiv thaiv - tiv thaiv kev npaj ua dua tshiab tom qab lub zog tsis ua haujlwm.

Theem Ua Ntej & Kev Tiv Thaiv Kev Tiv Thaiv Lub Zog - Xyuas kom muaj hluav taws xob phasing.

Luv-Circuit Court & overcurrent kev tiv thaiv - Circuit Court rooj tog thiab xa cov hluav taws xob kev nyab xeeb.

7. Cov neeg kho tshuab kom muaj kev nyab xeeb
Tsis yog & Bumper cov cuab yeej - nqus cov kev cuam tshuam thaum kawg ntawm kev mus ncig.

Rail clamps \/ anchoring li - nyab xeeb lub crane thaum tsis siv (rau cranes sab nraum zoov).

8. Neeg tsav tsheb muaj kev ruaj ntseg
Alarm nrog kev nyab xeeb deplocks - ua kom muaj kev nyab xeeb \/ tawm thiab kev ua haujlwm.

Pendant tswj nrog cov nyees khawm ua ke - txwv tsis pub muaj kev ua kom muaj.

Cov chaw uas tsis yog-galu- Guardrasns - rau kev saib xyuas zoo.

9. Saib xyuas & tswb
Ceeb Toom Horn & Beacon teeb - ceeb toom cov neeg ua haujlwm ua ntej Crane Dag.

Crane tshuaj xyuas qhov system (CMS) - Cov kev ua tau taug kev thiab pom kev ua txhaum.

10. Kev rov ua dua tshiab hauv cov tshuab
Dual braking System - thaub qab nres rau kev hoisting mechanisms.

Txoj hlua theem theem nrab retainer - tiv thaiv hlua khau khiab nyob rau hauv rooj plaub ntawm tsis ua haujlwm.





Daim duab kos

Cov Tshuab Tseem Ceeb







Ib qho 50 nyhav ob chav girder ua haujlwm ua haujlwm crane yog lub zog ua haujlwm hnyav tsim tsim kom muaj peev xwm muaj peev xwm, qauv zoo, thiab kav ntev. Ntawm no yog nws cov txiaj ntsig tseem ceeb:

1. Cov peev xwm siab thauj khoom muaj peev xwm (50 tons & tshaj)
Tsim los tuav cov nra hnyav (50 tons lossis ntau dua) zoo, ua rau nws zoo tagnrho rau cov nroj tsuag steel, partyards, cov nkoj xa khoom, thiab kev lag luam hnyav.

Yuav tuaj yeem kho tau rau cov peev xwm ntau dua yog tias xav tau.

2. Txhim Kho Kev Ruaj Ntseg & Durabe
Ob chav Girder tsim kho lub zog zoo dua thiab cov sib piv piv rau ib tus girder cranes.

Cov khoom xa tuaj zoo dua, txo kev ntxhov siab ntawm cov qauv crane.

Ua nrog cov hlau zoo rau kev ntseeg tau ntev hauv chaw hnyav.

3. Ntau Ntau Cov Xov Siab Qhov Siab & Lifting ntau yam
Lub ob chav girder tsim tso cai rau ntau dua nook qhov siab, loj heev ntsug ua haujlwm.

Qhov zoo tshaj plaws rau cov ntawv thov uas xav tau Lifting sib sib zog nqus (piv txwv li, hauv kev ua kom pom lossis cov khw muag khoom loj.

4. Advanced tswj & precision tuav
Nruab nrog kev sib txawv zaus zaus tsav (VFD) rau cov nrawm dua \/ deceleration, txo supter viav vias.

Precision muab tso rau qhov muag heev lossis muaj txiaj ntsig tus nqi.

Cov kev xaiv rau cov chaw taws teeb tswj & Automation rau kev nyab xeeb dua thiab ntau cov haujlwm ua haujlwm.

5. Customizable nta
Ntau yam hoisting tshuab (ib leeg \/ ob chav Hoist).

Cov Hooks tshwj xeeb, tuav, lossis cov hlau nplaum rau cov khoom sib txawv (steel, seem, ntim).

Kev tawg-pov thawj, kub-resistant, lossis corrosion-resistant variants rau huab kev mob heev.

6. Txo kev saib xyuas & lub neej ntev
Kev tsim kho kom zoo txo ​​cov hnav thiab kua muag.

Cov Bearings & High-qib cov khoom siv tsawg dua rau hnub.

Yooj yim rau kev kuaj thiab kho.

7. Kev ruaj ntseg nta
Kev tiv thaiv ntau dhau los tiv thaiv kev huam yuaj overloading.

Txwv kev hloov pauv & nres nres tsheb rau kev ua haujlwm zoo.

Anti-sib tsoo tshuab (rau ntau cranes nyob rau hauv tib bay).

8. Nqi rau kev lag luam hnyav
Siab dua tus nqi dua li ib leeg girder cranes, tab sis muaj zoo roi vim siv tau ntev, ua haujlwm tau zoo, thiab txo qis.

Cov ntawv thov zoo tagnrho:
Hlau & Hlau Ua

Lub nkoj nkoj thiab offshore kev lag luam

Fais fab nroj tsuag & cov tshuab hnyav

Loj-ntsuas kev tsim kho & Logistics

Xaus:
Ib qho 50- tuj tuj ua haujlwm ua haujlwm rau cov neeg ua haujlwm hnyav, muab lub zog, ua lub zog, thiab kev ntseeg tau rau hauv cov chaw muaj kev lag luam. Nws cov siab thauj khoom muaj peev xwm, kev siv zog ruaj khov, thiab kev xaiv customization tau tsim nws cov kev xaiv tshwj xeeb rau cov ntawv thov hnyav.





Ib qho 50 nyhav ob chav girder ua haujlwm ua haujlwm crane yog lub zog ua haujlwm hnyav tsim tau rau cov ntawv thov kev lag luam muaj peev xwm kev lag luam muaj peev xwm kev lag luam siab, meej thiab kav ntev. Hauv qab no yog nws cov ntawv thov tseem ceeb, nta, thiab cov txiaj ntsig:

Cov Ntawv Thov:
Hlau & Hlau Kev Lag Luam

Tuav hlau coil, daim hlau, thiab cov pwm hnyav.

Chaw thau khoom \/ unloading raw cov ntaub ntawv nyob rau hauv lub zog.

Fais fab nroj tsuag

Lifting turbines, cov tshuab hluav taws xob, thiab tshuab hnyav thaum saib xyuas.

Nkoj shipntilding & chaw nres nkoj

Tsiv cov nkoj loj thiab ntim.

Kev Machinery Nplua

Sib dhos cov khoom loj loj xws li nias, tsuas yog machinery, thiab cov tshuab hydraulic.

Kev Lag Luam Automotive

Thauj cov tsheb hnyav, presses, thiab cov kab sib dhos.

Kev Tsim Kho & Cov Txheej Txheem

Handling precast qhob ntu, cov choj Cheebtsam, thiab kab teeb duab.

MINING & MAAs cov nroj tsuag

Mus txav cov ntaub ntawv ntau, crushers, thiab kiln seem.





Cov txheej txheem ntau lawm rau 50 tuj ob chav girder overhead crane suav nrog ntau theem tseem ceeb, los ntawm kev tsim khoom thiab cov khoom siv los sib dhos thiab kev sim. Hauv qab no yog cov ncauj lus kom ntxaws ib kauj ruam-rau-kauj ruam txheej txheem ntawm kev tsim khoom lag luam:

1. Tsim & Engineering
Cov neeg siv khoom yuav tsum tau tshuaj xyuas: Txiav txim siab luv, Lifting qhov siab, Chav Kawm Ntawv (pojniam \/ ISO), thiab thaj chaw ua haujlwm.

Cad qauv: Tsim 3D tsim rau tus choj girders, kawg cabdia, hoist, thiab trolley.

Cov Txheej Txheem Txheej Txheem: Xam lo load muaj peev xwm, kev txwv tsis pub siv, thiab ua raws nrog cov qauv (ISO, DIN, pojniam, lossis CMAA).

Tsim Hluav Taws Xob & Tswj Lub Zog: Npaj lub cev muaj zog, xaim, thiab kev nyab xeeb hloov chaw (txwv kev tiv thaiv, kev tiv thaiv ntau dhau).

2. Cov Khoom Siv Pauv
Cov nqaj hlau loj: cov hlau zoo tais (Q235B \/ Q345B) rau lub thawv girders lossis cov ntu muab kauv.

Xaus Flriaes: Fabricated los ntawm cov hlau nrog welded lossis bolted kev tsim kho.

Hoist & trolley: ua kom muaj zog geavboxes, cov tsheb motors, hlua hlau, hooks, thiab nres.

Cheebtsam hluav taws xob: Cov Motors, Tswj Panels, Cov Hniav Nqaij, thiab Sensors.

3. Fabrication ntawm cov tseem ceeb
A. Ob Chav Girder Fabrication
Txiav & vuam: CNC ntshav txiav cov hlau nplaum, ua raws los ntawm submerged Arc vuam vuam (pom) rau girders.

Precision Machining: tho qhov rau kev sib txuas thiab cov teeb khiav tawm.

Txhaj Tshuaj Blasting & Painting: Kev Kho Nto Rau Corrosion Kuj (Primer + Topcoat).

B. Qhov kawg ntawm cov ntoo
Welded Assembluly: Fabricate log thaiv, buffers, thiab cov ntsiab lus sib txuas.

Log teeb tsa: Mount forged steel log nrog bearings.

C. Trolley & Hoist
NCAJ SIV: Tsim Trolley Ncej coj mus los pab txhawb 50T hoist.

Kev sib xyaw ua haujlwm: nruab nyem hlua Hlau nruas nruas nruas nruas nruas nruas nruas nruas nruas nruas nruas nruas ntaus, gearbox, thiab nuv thaiv.

4. Sib Dhom
Choj sib dhos: Koom nrog ob tus poj niam nrog cov tsheb ciav hlau kawg uas siv cov high-zog lub zog lossis vuam.

Trolley Mounting: Muab cov trolley ntawm tus choj choj; xyuas kom meej txoj kev ua kom du.

Cov Hluav Taws Xob Hluav Taws Xob: Nruab cov khoom siv hluav taws xob (Festoon lossis tus txiv neej cov tuav), tswj vaj huam, thiab cov khoom siv kev nyab xeeb.

5. Kuaj & Tswjhwm Zoo
Kev Tshawb Xyuas:

Tsis muaj-thauj mus kuaj: Tshawb xyuas lub cev muaj zog, nres, thiab kev txav ua haujlwm.

Qhov Ntsuas Zoo Li Qub: 125% ntawm SWL (62.5T) los xyuas cov qauv kev ntseeg.

Dynamic kev ntsuas: 110% ntawm SWL (55T) rau kev ua haujlwm ua haujlwm.

Cov tshev kev nyab xeeb: Tshawb nrhiav cov pob zeb hloov chaw, nres tsheb thaum muaj xwm ceev, thiab kev tiv thaiv kev tiv thaiv ntau dhau.

Ntawv pov thawj: Qhov teeb meem xeem ntawv (ib qho ISO 9001 lossis cov cai hauv zos).

6. Rho tawm & ntim
Dismantle crane rau kev xa khoom (yog tias yuav tsum tau).

Tiv thaiv cov khoom siv nrog cov tshuaj tiv thaiv xeb thiab ntim ruaj khov.

7. Txhim Kho & Chaw Haujlwm
Ntawm kev sib dhos ua ke: rov teev hawm Girders, Txhim kho cov kab teeb khiav, thiab duab suab.

Kev sim zaum kawg: Txheeb xyuas cov haujlwm du hauv qab thauj ntawm cov qhua tuaj noj mov.

Kev kawm: Cov neeg qhia ua haujlwm ntawm kev tswj hwm thiab txij nkawm.
