Ob chav Girder Gantry Crane Nrog Lifting Electric Hoist Winch Warehouse

Cov yam ntxwv tseem ceeb:

Ob chav Girder Design

Muab lub peev xwm nqa ntau dua (feem ntau yog 5 txog 550 tons) piv rau ib qho - nqaj gantry cranes.

Muab kev ruaj ntseg zoo dua thiab txo deflection nyob rau hauv hnyav loads.

Electric Hoist lossis Trolley System

Nruab nrog hluav taws xob hoist (hlau hlua los yog saw) rau ntsug nqa.

Lub trolley txav horizontally raws cov girders kom meej load positioning.

Gantry Structure

Txhawb nqa los ntawm cov ceg tawv (tso lossis kho qhov siab).

Ua tauib nrab-gantry(ib sab txhawb los ntawm lub tsev kem) los yogpuv gantry(tus kheej- txhawb nqa ntawm ob sab).

Mobility Options

Rail -mounted:Txav mus rau embedded lem rau hnyav - daim ntawv thov.

Log -mounted (rubber- nkees):Portable rau sab nraum zoov lossis siv ib ntus.

Tswj Systems

Pendant tswj (wired handheld chaw taws teeb).

Xov tooj cua tswj chaw taws teeb rau kev ua haujlwm yooj yim.

Cabin-ua haujlwm rau siab -cov haujlwm ua haujlwm raug.

Customizable Configurations

Ntev ntev (feem ntau yog 10-35 meters, ncua ntev).

Lifting qhov siab (kho tau raws li qhov yuav tsum tau ua).

Huab cua tsis zoo los yog tawg- pov thawj sib txawv rau qhov chaw hnyav.

Sib piv nrog Tib Beam Gantry Crane:

Lifting peev 320 tons
Ntev (dav) 3 - 12 meters (adjustable)
Lifting Qhov siab 3 - 10 meters
Chav Kawm Ua Haujlwm A3-A5 (lub teeb rau nruab nrab lub luag haujlwm)
Hoisting Ceev 0.5 - 8 m/min (variable)
Main Beam Hom Ib leeg / ob chav girder (lub thawv- hom)
Fais fab mov 220V / 380V 3-theem los yog phau ntawv
Tswj hom Pendant tswj / wireless chaw taws teeb
Hoist Hom Hluav taws xob saw hoist / hlau hlua hoist
Tsav Tsheb Tsav Tsheb Tsav Tsheb Tsav lossis Tsav Tsheb
Corrosion Protection Kub-dip galvanized lossis marine- qib xim
Cua Resistance Mus txog Beaufort nplai 6 (rau siv sab nraum zoov)
Kev khiav hauj lwm kub -20℃rau +50 degree

IbOb chav Girder Gantry Crane nrog Lifting Electric Hoist Winch Warehousemuaj ob peb yam tseem ceeb uas ua hauj lwm ua ke los xyuas kom meej tias kev nqa nqa tau zoo thiab muaj kev nyab xeeb. Hauv qab no yog cov ncauj lus kom ntxaws txog nws qhov tseem ceeb:

1. Main Girders (Bridge Beams)

Muaj nuj nqi:Thawj qhov kev thauj khoom-cov kabmob uas nthuav dav thaj chaw ua haujlwm.

Tsim:Ob qho tib si steel kem girders los yog kuv -beams rau siab zog thiab rigidity.

Nta:

Txhawb kom txo qis deflection nyob rau hauv hnyav loads.

Tej zaum yuav suav nrog kev taug kev rau kev saib xyuas (hauv cov cranes loj dua).

2. Xaus Carriages (Legs & Log)

Muaj nuj nqi:Txhawb cov girders thiab ua kom muaj kev txav mus los ntawm txoj kev khiav.

Cheebtsam:

Ob txhais ceg:Vertical lug (taag lossis adjustable qhov siab).

Log & Buffers:

Rail -mounted:Steel log rau taug kev txav.

Roj hmab- nkees:Mobile cranes tsis muaj rails.

Buffers:Shock absorbers los tiv thaiv kev sib tsoo.

Tsav Mechanism:Fais motors rau gantry mus txawv tebchaws (tej zaum yuav yog ib leeg lossis dual tsav).

3. Hoist & Trolley System

Muaj nuj nqi:Tuav ntsug lifting thiab kab rov tav txav ntawm loads.

Cheebtsam:

Electric Hoist:

Hlau hlua hoist (rau hnyav loads).

Saw hoist (rau sib dua, meej nqa).

Trolley Ncej:Tsiv raws cov girders ntawm motorized log.

Lifting Hook / Grab:Txuas rau lub load (tuaj yeem kho tau rau kev siv tshwj xeeb).

4. Khiav System

Muaj nuj nqi:Muab txoj hauv kev rau gantry txav.

Hom:

Embedded Rails:Tsau kab rau hnyav- daim ntawv thov haujlwm.

Nto-Mounted Rails:Yooj yim rau nruab, siv hauv kev cob qhia.

Roj Hmab-Nyuaj (Tsis Muaj Rails):Rau mobile gantry cranes.

5. Hluav taws xob & Tswj Systems

Cheebtsam:

Lub cev muaj zog:

Hoist lub cev muaj zog (rau nqa).

Trolley motor (rau hla-travel).

Gantry mus ncig teb chaws motors (rau longitudinal txav).

Tswj Vaj Huam Sib Luag:Lub tsev contactors, relays, thiab overload protectors.

Tus neeg khiav dej num tswj:

Pendant Control:Wired handheld chaw taws teeb.

Xov tooj cua chaw taws teeb:Kev ua haujlwm wireless.

Operator Cabin:Rau siab - precision lossis nquag siv.

Cov cuab yeej kev nyab xeeb:

txwv kev hloov pauv (kom tiv thaiv dhau- mus ncig).

Kev tiv thaiv overload (txiav fais fab yog tias muaj peev xwm tshaj).

Emergency stop (E-stop) khawm.

6. Braking System

Hom:

Mechanical Brakes:Caij nplooj ntoos hlav-loaded nres nres.

Regenerative Braking:Rov qab muaj zog nyob rau hauv niaj hnub cranes.

Muaj nuj nqi:Xyuas kom du nres thiab tuav cov loads ruaj ntseg.

7. Lwm yam Cheebtsam

Cabin (Yeem):Chaw nres tsheb tus neeg teb xov tooj kaw kom pom kev zoo dua.

Teeb pom kev & tswb:Cov cim ceeb toom rau kev ua haujlwm nyab xeeb.

Anti-Sway System (Yeem):Txo load viav vias rau precision lifting.

Festoon / Cable Reel:Tswj fais fab thiab tswj cables.

Cov ntsiab lus tseem ceeb thaum xaiv cov khoom:

Load Capacity & Span:Txiav txim siab girder loj thiab lub cev muaj zog.

Lub luag haujlwm Cycle:Kev siv ntau zaus yuav tsum hnyav - lub cev muaj zog thiab nres.

Ib puag ncig:Corrosive lossis explosive thaj chaw yuav tsum tau coatings tshwj xeeb / fixtures.

Fais fab mov:Feem ntau 3-theem AC (380V, 480V, thiab lwm yam).

SKETCH

Main technical

Ob chav Girder Gantry Crane nrog Lifting Electric Hoist Winch Warehouse yog dav siv nyob rau hauv hnyav industries vim lawv superior zog, stability, thiab versatility. Nov yog cov txiaj ntsig tseem ceeb:

1. Siab Load Capacity (Txog 550+ Tons)

Tsim los rau hnyav- lub luag haujlwm nqa, ua rau lawv zoo tagnrho rau cov nroj tsuag steel, shipyards, thiab kev tsim kho.

nruj dua ib zaug - nqaj cranes, txo deflection nyob rau hauv hnyav loads.

2. Dav dav dav dav (10–{2}} Meters)

Haum rau cov chaw ua haujlwm loj xws li warehouses, ports, thiab manufacturing halls.

Muaj peev xwm kho tau rau ntxiv - dav spans nrog reinforced girders.

3. Txhim khu kev ruaj ntseg & Durability

Ob chav girders faib qhov hnyav sib npaug, txo qis sway thiab kev co.

Kev tsim kho steel muaj zog ua kom muaj kev ua haujlwm ntev - nyob rau hauv ib puag ncig hnyav.

4. Ntau dua Lifting Qhov siab

Ua kom cov khoom siab dua piv rau ib qho - nqaj cranes.

Adjustable girder qhov siab rau kev siv tshwj xeeb.

5. Precise & Smooth ua haujlwm

Nruab nrog sib txawv - tswj ceev kom raug load positioning.

Anti-sway technology muaj rau kev ua haujlwm me me.

6. Kev xaiv yooj yim rau kev txav mus los

Rail -mounted:Qhov zoo tshaj plaws rau kev txhim kho sab hauv tsev / sab nraum zoov.

Roj hmab- nkees:Portable rau qhov chaw ua haujlwm ib ntus.

7. Cov yam ntxwv ntawm kev nyab xeeb

Kev tiv thaiv ntau dhau, txwv kev hloov pauv, nres thaum muaj xwm txheej ceev, thiab ua tsis tiav -kev nyab xeeb xauv.

Optional cabin los yog tej thaj chaw deb tswj rau tus neeg teb xov tooj kev nyab xeeb.

8. Kev tu qis & Lub neej ua haujlwm ntev

High - cov khoom zoo txo ​​qhov hnav thiab tsim kua muag.

Yooj yim rau kev tshuaj xyuas thiab kho.

Cov cranes no yog qhov tseem ceeb hauv kev lag luam uas xav tau kev nqa hnyav, kev tuav nruj, thiab kev pabcuam dav. Cov ntawv thov uas muaj xws li:

1. Hlau & Hlau Kev Lag Luam

Kev tuav cov hlau coils, daim hlau, thiab castings.

Loading / unloading nyob rau hauv dov mills thiab foundries.

2. Shipbuilding & Chaw nres nkoj

Kev sib sau ua ke ntawm nkoj.

Txav cov thawv thiab cov khoom hnyav hauv cov chaw nres nkoj.

3. Kev tsim kho & kev tsim vaj tsev

Lifting precast qhob kab teeb thiab choj ntu.

Kev thauj cov tshuab hnyav rau ntawm -site.

4. Lub zog cog

Txhim kho turbines, generators, thiab transformers.

Kev tu cov boilers thiab cov khoom hnyav.

5. Railway & Aerospace

Sib sau ua ke cov tsheb ciav hlau.

Tuav cov khoom siv dav hlau hauv hangars.

6. Mining & Heavy Machinery

Tsiv cov khoom siv mining loj xws li crushers thiab excavators.

7. Warehouse & Logistics

stacking hnyav pallets hauv cov chaw khaws khoom loj.

Cov txheej txheem tsim khoom ntawm ob chav Girder Gantry Crane nrog Lifting Electric Hoist Winch Warehouse muaj ob peb theem, los ntawm kev tsim thiab engineering mus rau fabrication, sib dhos, thiab kev sim. Hauv qab no yog cov ncauj lus kom ntxaws txog cov txheej txheem ntau lawm:

1. Tsim & Engineering

Tswv yim tsim:Cov kws tsim qauv tsim cov duab kos thiab 3D qauv raws li qhov muaj peev xwm thauj khoom (200 tons), ncav cuag, txav mus los, thiab ib puag ncig (kev siv dej hiav txwv).

Structural Analysis:Finite Element Analysis (FEA) kom ntseeg tau tias lub crane tuaj yeem tuav cov khoom hnyav, cua, thiab nthwv dej.

Hydraulic & Hluav Taws Xob Systems:Tsim cov hydraulic cylinders, winches, thiab tswj cov tshuab ua haujlwm kom du.

Kev xaiv khoom siv:Siab -lub zog steel (xws li ASTM A514) rau corrosion kuj nyob rau hauv marine ib puag ncig.

Txoj Cai Ua Raws Cai:Ua tau raws li cov qauv zoo liDNV-GL, ABS, lossis Lloyd's Registerrau marine cranes.

2. Kev yuav khoom

Steel Phaj & Beams:Tau txais kev txhawb nqa rau lub boom, chassis, thiab structural moj khaum.

Hydraulic Cheebtsam:Cov twj tso kua mis, lub tog raj kheej, hoses, thiab li qub los ntawm cov neeg muab ntawv pov thawj.

Hluav taws xob Systems:Motors, sensors, thiab tswj vaj huam sib luag (feem ntau waterproof rau marine siv).

Hlau Ropes & Sheaves:High -qib steel cables rau nqa.

3. Kev tsim khoom

A. Qauv Fabrication

Txiav & Shaping:CNC plasma / laser txiav rau precision qhov chaw.

Vuam:Automated thiab phau ntawv vuam (Submerged Arc Vuam rau cov ntu tuab).

Kev tsim kho Boom:Lattice lossis telescopic tsim rau lub zog thiab kev txav mus los.

Chassis & Outriggers:Ntxiv dag zog rau kev ruaj ntseg thaum nqa.

B. Hydraulic & Mechanical Assembly

Hydraulic System:Kev txhim kho cov twj tso kua mis, lub tog raj kheej, thiab hoses.

Winches & Drums:Mounted rau lifting thiab txo cov haujlwm.

Slewing Mechanism:Tso cai 360℃tig (yog tias tsim nyog).

C. Hluav taws xob & Tswj Systems

Control Cabin:Waterproof tus neeg teb xov tooj chaw nres tsheb nrog joysticks / sensors.

Load Monitor:Load cells thiab txwv cov keyboards kom muaj kev nyab xeeb.

Fais fab mov:Diesel cav lossis hluav taws xob lub cev muaj zog (marine-qib).

4. Kev sib dhos & kev sib koom ua ke

Boom Installation:Mounted rau lub chassis nrog pivot ntsiab lus.

Counterweights:Ntxiv rau qhov sib npaug (yog tias xav tau).

Xauv thiab kav dej zaum kawg:Txuas hydraulic thiab hluav taws xob systems.

Painting & Txheej:Anti- xim xim (epoxy lossis zinc txheej).

5. Kev Ntsuas & Kev Tswj Xyuas Zoo

Load Test:Lifting 200 tons (+25% overload test, per standard).

Kev Xeem Ua Haujlwm:Tshawb xyuas hydraulic txav, kev sib hloov, thiab kev ruaj ntseg.

Environmental Tests:Ntsev tshuaj ntsuam xyuas rau marine durability.

Kev Ntsuam Xyuas Kev Nyab Xeeb:Emergency stop systems, overload alarms.

6. Kev xa khoom & xa tawm

Kev thauj mus los:Disassembled rau shipping los yog xa raws li ib tug mobile unit.

Ntawm -Site Assembly:Reassembled ntawm qhov chaw nres nkoj lossis chaw nres nkoj.

Kev cob qhia neeg ua haujlwm:Kev tuav thiab kev ruaj ntseg raws tu qauv.
