Underhung Choj Crane





Lub underhung choj crane yog cov khoom siv ntau yam thiab qhov chaw siv tau zoo, siv dav hauv kev lag luam uas yuav tsum tau nqa thiab thauj cov khoom hnyav. Tsim los ua haujlwm nrog nws cov kab ke taug qab nyob rau hauv qab ntawm lub tsev lub ru tsev lossis lwm yam kev txhawb nqa, underhung cranes ua kom qhov chaw hauv pem teb kom zoo tshaj plaws thiab txhim kho kev ua haujlwm hauv cov chaw kaw lossis cov chaw kaw.

Underhung choj cranes yog tsim los nrog cov ntaub ntawv zoo los tiv thaiv kev lag luam hnyav thiab kev siv hnyav. Lub compact tsim thiab configuration ntawm underhung choj crane tso cai rau nws mus ua hauj lwm nyob rau hauv qis-headroom qhov chaw, ua rau nws yog ib qho kev xaiv zoo tagnrho rau cov chaw uas tsis muaj headroom.

Underhung choj cranes siv cov txheej txheem tswj kev ua haujlwm kom ntseeg tau tias kev thauj khoom raug raug thiab txhim kho kev ua haujlwm nyab xeeb. Lawv muaj nyob rau hauv ntau yam lifting peev thiab spans kom tau raws li ntau yam kev lag luam xav tau.

Lub underhung choj crane yog ib qho kev daws teeb meem tshiab rau kev lag luam tab tom nrhiav kom ua tau zoo tshaj plaws, kev nyab xeeb, thiab kev siv qhov chaw hauv lawv cov haujlwm.

Core Cheebtsam: PLC, Bearing, Gearbox, Tsav, Iav

Qhov chaw ntawm Keeb Kwm: Henan, Suav

Warranty: 1 Xyoo

Qhov hnyav (KG): 500 kg

Video tawm-kev tshuaj xyuas: Muab

Machinery Test Report: Muab

Xim: Customized

Crane feature: Yooj Yim Ua Haujlwm Girder Choj Crane

Peev xwm: 1-20t

Hom: Ib leeg Girder

Lub hwj chim: 110V / 220V / 230V / 380V / 440V

Txoj Kev Tswj: Hauv av tswj + Chaw taws teeb tswj (customized)

MOQ: 1set

Lifting mechanism: Hluav taws xob Hoist

Lub luag haujlwm ua haujlwm: A3-A4





1.Main beam

1) Lub ntsiab nqaj ntawm tus choj underhung crane yog ib qho tseem ceeb ntawm cov txheej txheem uas cuam tshuam qhov sib txawv ntawm crane cov kev txhawb nqa, xws li cov kab hluav taws xob los yog phab ntsa. Tsis zoo li tus choj ua haujlwm saum toj kawg nkaus, lub crane underhung muaj nws cov tsheb thauj khoom kawg uas tau teeb tsa hauv qab cov kab ciav hlau khiav uas tso cai rau lub ntsiab nqaj kom dai hauv qab cov qauv siv nyiaj siv ua haujlwm.

Tus Qauv Tsim: Ua los ntawm cov hlau, feem ntau yog ib leeg girder (I-beam) los yog ob chav girder rau hnyav loads.Designed nqa lub load qhov hnyav thiab faib nws tusyees mus rau lub kawg tsheb.

Suspension System: Lub nqaj dai hauv qab txoj kab khiav thiab tau txais kev txhawb nqa los ntawm cov log ntawm cov tsheb thauj khoom kawg uas taug kev raws cov kab hauv qab.

Load Capacity: Tus tsim thiab loj nyob ntawm seb lub crane load peev xwm, ncua, thiab daim ntawv thov.Larer muaj peev xwm yuav tsum tau reinforced los yog lub thawv girders los tiv thaiv deflection thiab kev ntxhov siab.

Kev koom ua ke nrog Hoist: Txhawb nqa hluav taws xob lossis phau ntawv hoist uas txav kab rov tav raws kab.



2. Lifting System

Lub cev muaj zog: Lub cev muaj zog yog lub luag haujlwm rau kev txhawb nqa lub tshuab nqa, ua kom lub crane nce, qis dua, lossis tuav cov khoom thauj. Nws qhov kev ua tau zoo cuam tshuam rau crane qhov ua tau zoo, precision, thiab kev nyab xeeb.

Reducer: Lub reducer nyob rau hauv lub lifting system rau ib tug underhung choj crane plays lub luag hauj lwm tseem ceeb nyob rau hauv lub crane tus neeg kho tshuab system los ntawm kev txo lub siab input ceev los ntawm lub cev muaj zog mus rau ib tug qis tso zis ceev, yog li nce torque. Qhov no yog qhov tseem ceeb rau kev nqa cov khoom hnyav thiab ua kom muaj kev ua haujlwm zoo.

Nruas: Lub nruas lifting system nyob rau hauv ib tug underhung choj crane yog ib qho tseem ceeb tivthaiv uas tuav lub lifting thiab txo cov loads.A cylindrical tivthaiv nyob ib ncig ntawm uas cov hlau hlua los yog cable yog mob.Ua los ntawm high-zog steel tiv thaiv load stresses.Often grooved los xyuas kom zoo winding ntawm txoj hlua thiab txo qis hnav.

Hlau hlua: Cov hlua hlau nyob rau hauv lub tshuab nqa ntawm tus choj underhung crane ua lub luag haujlwm tseem ceeb hauv kev ua kom muaj kev nyab xeeb thiab ua haujlwm zoo ntawm crane. Nws yuav tsum tuav lub siab nruj thiab hnav yam tsis muaj qhov tsis ua haujlwm los tiv thaiv kev sib tsoo.Cov hlua hlau yog lub luag haujlwm rau kev xa cov quab yuam los ntawm lub hoist mechanism mus rau qhov chaw thauj khoom.

Pulley thaiv: Cov no yog cov log grooved tsim los coj cov hlua hlau los yog cov saw hlau.Lawv txo cov kev siv zog uas xav tau los nqa lub nra los ntawm kev nthuav tawm qhov nro hla ntau ntu ntawm txoj hlua. Feem ntau yog ua los ntawm cov khoom siv ruaj khov xws li steel lossis hlau alloys. thaiv feem ntau dai hauv qab lub hoist trolley, uas txav raws tus choj.

Lifting ntaus ntawv: Cov cuab yeej nqa ntawm tus choj underhung crane yog ib qho tseem ceeb ntawm lub luag haujlwm rau hoisting thiab txo cov loads yam xyuam xim thiab ua tau zoo. Nyob rau hauv cov ntsiab lus ntawm ib tug underhung choj crane, lub lifting system feem ntau yog tsim los optimize kev siv ntawm qhov chaw thiab txhim khu versatility nyob rau hauv daim ntawv thov xws li warehouses, workshops, thiab manufacturing chaw.



3.Endlub tsheb

1) Kev thauj mus los kawg ntawm tus choj crane crane yog ib qho tseem ceeb uas muab kev txhawb nqa thiab kev txav mus los rau tus choj crane. Underhung choj cranes, tseem hu ua underhung cranes, muaj lawv tus choj raug tshem tawm ntawm lub tsev qauv lossis cov kab hluav taws xob khiav, tso cai rau kev siv qhov chaw zoo hauv cov chaw uas tsis muaj lub taub hau.

2) Lub tsheb thauj neeg kawg yog tsim los kom tshem tawm ntawm cov kab hluav taws xob overhead khiav.

3) Qee qhov kawg cov tsheb thauj khoom tso cai rau kev hloov kho me ntsis kom haum rau txoj kev khiav, ua kom muaj kev ua haujlwm zoo.Cov tsheb thauj neeg kawg tau txuas nrog tus choj girder (s), ua tiav crane system.Kev sib txuas yog bolted lossis welded rau kev ruaj ntseg txuas.

4.Crane mus ncig teb chaws mechanism

1) Txoj cai ua haujlwm

Lub crane yog mounted nyob rau hauv underside ntawm ib tug choj los yog khiav system, uas feem ntau yog txhawb los ntawm overhead beams los yog rails. Nyob rau hauv ib qho underhung crane, tus choj raug tshem tawm los yog "underhung" los ntawm cov qauv nyiaj siv ua haujlwm, es tsis yog kev txhawb nqa los ntawm hauv av.Lub crane feem ntau khiav raws kev tsheb ciav hlau lossis kab teeb tsa ntawm tus choj. Cov kev tsheb ciav hlau no tau txais kev txhawb nqa los ntawm cov qauv nyiaj siv ua haujlwm, muab txoj hauv kev ruaj khov rau cov crane taug kev horizontally. Cov txheej txheem kev mus los yog siv cov log lossis cov tsheb thauj khoom uas txuas rau ntawm tus choj hauv qab. Cov log no txuas nrog lub cev muaj zog thiab lub tshuab tsav, ua kom lub crane txav raws tus choj ntev.Qhov kev txav ntawm lub crane yog tsav los ntawm lub tshuab hluav taws xob lossis ib txheej ntawm lub cev muaj zog. Cov motors no feem ntau txuas nrog lub log ntawm lub iav mechanism. Lub cev muaj zog lub zog yog xa mus rau lub log, ua rau lawv tig thiab txav mus rau lub crane raws li cov rails.Lub cev muaj zog tuaj yeem ntsia tau rau ntawm tus choj crane nws tus kheej lossis ntawm lub tsheb thauj mus los, nyob ntawm tus qauv tsim. Nws kuj tseem siv tau ua ke ntawm hluav taws xob, hydraulic, lossis pneumatic systems rau kev txav mus los.Tus neeg teb xov tooj tswj cov txheej txheem mus ncig uas siv lub vaj huam sib luag tswj lossis cov chaw taws teeb tswj. Qhov kev tswj no kho qhov ceev thiab kev taw qhia ntawm lub cev muaj zog uas tsav lub log tsheb trolley.

2) Kev ua haujlwm ntawm crane khiav haujlwm mechanism

Hoisting Mechanism (Lifting) Muaj nuj nqi: Kev mus ncig ua haujlwm tso cai rau tag nrho tus choj ntawm underhung crane txav horizontally raws cov kab ciav hlau khiav.

Load Positioning Function: Los ntawm kev txav tus choj thiab lub hoist mechanism ua ke, tus neeg teb xov tooj crane tuaj yeem tso lub load kom raug raws li qhov xav tau qhov chaw.

Smooth Load Transfer: Lub tshuab ua kom du thiab tswj kev mus los kom tsis txhob muaj lub suab nrov uas tuaj yeem ua rau lub nra hnyav lossis tsim kom muaj kev nyab xeeb.

Load Distribution: Cov txheej txheem mus ncig sib npaug sib npaug faib qhov hnyav ntawm cov khoom hla ntawm txoj kab khiav.



5.Trolley mus ncig teb chaws mechanism

1) Cov qauv tsim qauv

Trolley Ncej: Lub trolley thav duab yog cov qauv tseem ceeb uas txhawb nqa tag nrho lwm yam khoom ntawm lub trolley system, nrog rau lub hoist, lub log, thiab tsav system. kev ua haujlwm.Lub thav duab hauv tsev hoist chav tsev thiab muab lub platform rau lwm yam khoom siv.

Cov Tsheb Thauj Mus Los (Trolley Log): Cov log no tau muab tso rau ntawm ob sab ntawm lub trolley thav duab thiab tso cai rau lub trolley txav raws txoj kev tsheb ciav hlau ntawm tus choj underhung.Cov log feem ntau yog ua los ntawm cov hlau thiab haum nrog cov kabmob kom txo tau kev sib txhuam thiab hnav. .Lawv tau muab tso rau kom ntseeg tau tias kev txav mus los ntawm kev sib tw, nrog lub log hloov kho kom haum rau kev sib raug zoo nrog tus choj lub girder.

Tsav Mechanism (Electric Tsav thiab Gearbox): Lub trolley feem ntau yog tsav los ntawm lub tshuab hluav taws xob, feem ntau siv lub zog siv hluav taws xob xa hluav taws xob rau lub log.Lub cev muaj zog tuaj yeem ntsia tau rau ntawm lub trolley thav duab lossis ntawm ib qho chaw tsav tsheb sib txuas nrog lub trolley. los ntawm ib tug ncej los yog saw.Qhov tsav mechanism muab qhov tsim nyog torque txav lub trolley hla tus choj.

Trolley Rail: Lub trolley taug kev ntawm txoj kev tsheb ciav hlau, feem ntau yog ntsia rau hauv qab ntawm tus choj qauv. Cov ntsia hlau yog ua raws li kev ua kom zoo thiab ruaj khov ntawm lub trolley.Cov ntsia hlau no feem ntau yog ua los ntawm cov hlau zoo los tuav cov khoom thauj los ntawm lub crane system.

Gearbox thiab Couplings: Lub gearbox txo qhov ceev ntawm lub cev muaj zog thiab nce torque, uas yog kis tau mus rau lub log los ntawm cov couplings.Couplings txuas lub cev muaj zog los yog gearbox rau lub log tsav, kis tau tus neeg kho tshuab zog zoo.

Braking System: Txhawm rau nres thiab tswj kev txav ntawm lub trolley, lub braking system yog qhov tseem ceeb. Qhov no tej zaum yuav muaj hluav taws xob los yog cov neeg kho tshuab nres uas siv rau lub log tsheb los yog lub cev muaj zog nws tus kheej.Lub braking system yog tsim los tuav lub trolley nyob rau hauv qhov chaw thaum tsis siv thiab decelerate nws smoothly thaum lub sij hawm ua hauj lwm.

2) Kev ua haujlwm ntawm lub trolley kev khiav haujlwm mechanism

Lub trolley mus ncig teb chaws mechanism ntawm tus choj underhung crane plays lub luag haujlwm tseem ceeb hauv kev txav ntawm lub crane raws qhov ntev ntawm tus choj. Nws tso cai rau lub crane taug kev horizontally hla tus qauv, tso cai rau nws tso nws tus kheej kom meej rau ntau qhov chaw thauj khoom.



6.Crane log

Lub log crane nyob rau hauv xws li kev teeb tsa ua haujlwm tseem ceeb rau kev txav ntawm crane raws txoj kev khiav. Cov log no feem ntau yog ntsia rau ntawm cov tsheb thauj khoom kawg (kawg carriages) ntawm tus choj crane thiab muaj cov qauv tsim tshwj xeeb rau kev ua haujlwm du.

Khoom siv: Feem ntau yog ua los ntawm cov hlau muaj zog los yog cov ntaub ntawv alloyed kom tiv taus cov khoom hnyav thiab tiv taus hnav.

Puab: Tej zaum yuav tiaj tus, crowned, los yog tapered nyob ntawm txoj kev tsheb ciav hlau kom pom kev sib koom tes thiab txav mus los.

Mounting: Cov log feem ntau yog ntsia rau ntawm cov axles txuas nrog lub crane kawg cov tsheb thauj khoom, thiab lawv tau tsim los kom haum rau me me misalignments hauv txoj kev khiav.

Load Distribution: Cov log yog tsim los faib cov khoom sib npaug ntawm cov kab hauv qab, txo qhov hnav ntawm txoj kev khiav thiab cov khoom siv crane.

Adjustability: Cov log lossis lawv cov mountings yuav muaj cov yam ntxwv kho tau kom haum rau txoj kev khiav.

7.Crane Hook

Lub crane nuv ntawm tus choj underhung crane plays lub luag haujlwm tseem ceeb hauv kev nqa thiab tuav cov khoom thauj. Feem ntau yog tsim los ntawm forged alloy steel rau siab zog thiab durability. Features nkhaus los yog "C" zoo, ua kom ruaj ntseg txuas rau slings, chains, los yog nqa khoom.

Hom: Ib Hook: Siv rau cov khoom sib dua. Ob Chav Hook: Haum rau hnyav thiab sib npaug loads.Safety Nta: kev nyab xeeb latch kom tiv thaiv kev sib tsoo ntawm lub load.Swivel mechanism rau kev sib hloov du, txo txoj hlua los yog saw twisting.

Tus nuv yog txuas rau lub hoist mechanism ntawm: Ib txoj hlua hlau los yog saw rau lifting.A pulley system rau cov neeg kho tshuab kom zoo dua.Lub hoist trolley khiav raws qab flange ntawm underhung crane lub girder, faib hnyav npaum li cas.

Lub cev muaj zog

Lub cev muaj zog ntawm tus choj underhung crane ua lub luag haujlwm tseem ceeb hauv kev tsav lub crane txav thiab ua kom nws nqa thiab thauj khoom tau zoo.

Lub hom phiaj

Hoisting Tsav: Fais lub lifting mechanism, enabling ntsug txav ntawm loads.

Trolley Tsav: Tsav lub trolley uas txav lub hoist raws tus choj.

Choj Tsav: Tsav lub zog ntawm tag nrho cov crane raws nws txoj kev khiav.

Ntsiab nta

Fais fab thiab Torque: txaus los tuav lub ntsuas load ntawm crane.

Lub luag haujlwm Cycle: Rated rau kev sib tshuam lossis kev ua haujlwm tas mus li raws li lub crane daim ntawv thov.

Kev Nyab Xeeb: Nruab nrog cov yam ntxwv zoo li lub tshuab braking kom tuav cov khoom hauv qhov chaw.

Durability: Tsim los tiv thaiv kev lag luam ib puag ncig.

Kev txiav txim siab ntxiv

Ib puag ncig tej yam kev mob: Motors yuav tsum tau tiv thaiv plua plav, ya raws, thiab kub heev.

Energy Efficiency: Xaiv lub tshuab ua haujlwm siab kom txo tau lub zog siv.

Kev Kho: Yooj yim nkag mus rau kev tshuaj xyuas thiab kho..

.

Suab thiab lub teeb tswb system & txwv hloov

1) Suab thiab lub teeb tswb system

Lub suab nrov thiab lub teeb ceeb toom rau lub underhung choj crane yog ib qho tseem ceeb ntawm kev nyab xeeb uas txhim khu kev paub txog kev ua haujlwm thiab txo qhov kev pheej hmoo ntawm kev raug mob.

Audible Alarms (Suab):

Hom: Buzzers, sirens, lossis hais lus.

Qib suab: Feem ntau ntawm 85-120 dB kom ntseeg tau tias muaj suab nrov hauv ib puag ncig nrov.

Nta: Nruam los yog tsis tu ncua tones.Programmable suab qauv rau txawv theem ceeb toom.Volume tswj kom phim ib puag ncig.

Visual Alarms (Lub teeb):

Hom: flashing LED teeb, strobe teeb, lossis beacon teeb.

Liab: Kev phom sij lossis kev saib xyuas tam sim.

Yellow / Amber: Ceev faj lossis ceeb toom ua ntej.

Ntsuab: Muaj kev nyab xeeb (yeem).

Nta: High-siv illumination rau visibility.Rotating los yog pulsing lub teeb qauv.Weatherproof thiab check casings rau industrial ib puag ncig.

Limit hloov.

Ib qho kev txwv kev hloov pauv yog ib qho tseem ceeb ntawm kev nyab xeeb thiab cov cuab yeej ua haujlwm tau teeb tsa nyob rau hauv underhung choj cranes (los yog nyiaj siv ua haujlwm cranes). Nws yog siv los tswj thiab txwv kev txav ntawm lub crane lossis hoist, ua kom muaj kev nyab xeeb thiab tiv thaiv kev mus los lossis kev sib tsoo.

Kev Ua Haujlwm: Nres lub hoist lossis crane thaum nws mus txog qhov kawg ntawm nws qhov kev tso cai mus txawv tebchaws, horizontally raws tus choj lossis vertically nrog lub hoist. Tiv thaiv lub crane thiab ib puag ncig cov qauv los ntawm kev puas tsuaj los ntawm overextension. txwv txoj kev mus rau thaj chaw tshwj xeeb hauv thaj chaw ua haujlwm txhawm rau txhim kho qhov tseeb thiab kev nyab xeeb.

Hom: Rotary Limit Hloov: Nruab rau ntawm lub hoist mechanism.Ua haujlwm los ntawm kev ntsuas tus naj npawb ntawm cov kiv puag ncig ntawm lub nruas lossis lub cev muaj zog los tswj lub zog ntsug ntawm lub hoist.Lever / Plunger-Type Limit Hloov: Ua kom muaj zog los ntawm kev sib cuag ntawm lub cev nrog kev txav. ib feem (xws li crane trolley los yog choj). Feem ntau siv rau kab rov tav motion limits.Magnetic Limit Switch: Siv Sib nqus sensors los ntes cov haujlwm yam tsis muaj kev sib cuag ntawm lub cev. Muaj kev ntseeg siab nyob rau hauv ib puag ncig uas av lossis hnav tuaj yeem cuam tshuam rau cov khoom siv hluav taws xob.Txoj kev txwv Hloov: Tshawb xyuas cov khoom lossis cov haujlwm yam tsis muaj kev sib cuag, siv infrared, ultrasonic, lossis electromagnetic signals.Common nyob rau hauv niaj hnub cranes kom meej, tsis - tiv tauj kom paub meej.



10. Cov khoom siv ruaj ntseg

Overload Protection System: Load Cells lossis Overload Limiters: Saib xyuas lub thauj khoom raug nqa thiab nres ua haujlwm yog tias nws dhau ntawm lub crane qhov muaj peev xwm.Limit Switches Function: Tiv thaiv lub crane los ntawm kev txav mus dhau nws cov kev txwv kev nyab xeeb.

Anti-Sway Mechanism Function: Sensors los yog qhov sib thooj detectors los tiv thaiv kev sib tsoo ntawm ntau lub cranes ntawm tib txoj kev khiav los yog nruab nrab ntawm crane thiab lwm yam teeb meem.

Emergency Stop Button Function: Nyob ntawm tus tswj pendant, tus neeg teb xov tooj lub tsev, lossis chaw taws teeb tswj. Tam sim ntawd nres tag nrho cov crane txav thaum muaj xwm ceev.

Infrared lossis Laser Sensors Function: Built-in sensors rau kev saib xyuas hnav, deformation, lossis ua haujlwm tsis zoo hauv cov khoom tseem ceeb.

Load viav vias Control: Advanced cranes yuav suav nrog cov cuab yeej siv hluav taws xob los tiv thaiv lub viav vias thaum ua haujlwm, ua kom muaj kev ruaj ntseg thiab kev nyab xeeb.



11.Control hom

Manual Control (Pendant Control) Nqe lus piav qhia: Lub crane yog ua manually, feem ntau ntawm lub pendant tswj lub thawv los yog ib tug handheld tej thaj chaw deb.Tus neeg teb xov tooj nyob ze rau ntawm lub crane.Siv rau yooj yim, tsis tshua muaj peev xwm cranes.

Semi-Automatic Control: Qee lub luag haujlwm (xws li kev txav ntawm tus choj lossis hoisting) yog automated, thaum lwm tus xav tau phau ntawv input.Combines tib neeg kev ua haujlwm nrog kev pabcuam automated.Increases efficiency rau repetitive ua hauj lwm.Obly siv nyob rau hauv workflows nrog zoo ib yam load qauv.

Tag Nrho Tsis Siv Neeg Tswj: Lub crane ua haujlwm autonomously, ua cov haujlwm ua ntej ua haujlwm yam tsis muaj kev cuam tshuam ntawm lub sijhawm tiag tiag.Utilizes sensors, programmable logic controllers (PLCs), lossis computerized systems.

Sketch





Main technical







Space Efficiency: Lub underhung tsim yuav tsum tsawg headroom piv rau saum-khiav cranes, ua rau nws zoo tagnrho rau cov chaw uas tsis muaj qab nthab.Cov cranes no yuav mounted rau lub tsev lub ru tsev los yog qab nthab qauv, tshem tawm qhov yuav tsum tau rau ntxiv kev txhawb nqa.

Flexibility nyob rau hauv Installation: Underhung cranes muaj peev xwm ua hauj lwm nyob rau hauv nkhaus lem, muab ntau yooj yooj yim nyob rau hauv layout rau complex workflows.Lawv yuav muab ntsia rau hauv nruj los yog txwv qhov chaw uas lwm yam crane yuav tsis haum.

Tus Nqi-Kev Ua Tau Zoo: Vim tias lawv tsis tas yuav muaj cov kab ke ib leeg, cov nqi teeb tsa tuaj yeem qis dua.Underslung cranes feem ntau sib dua li cov cranes saum toj kawg nkaus, txo cov qauv ntawm lub tsev.

Txhim khu kev nkag tau yooj yim: Cov cranes no tsim nyog rau daim ntawv thov uas yuav tsum tau crane npog ze ntawm phab ntsa lossis lwm yam kev thaiv.Qhov tsim tso cai rau kev nkag mus rau qhov chaw tsis tuaj yeem ncav cuag los ntawm lwm hom cranes.

Txhim kho kev nyab xeeb: Lub crane txoj hauj lwm underhung tuaj yeem ua rau muaj kev ruaj ntseg hauv qee yam kev siv.Minimizes qhov kev pheej hmoo ntawm kev sib tsoo hauv qhov chaw kaw.

Kev siv ntau yam: nquag siv hauv kev tsim cov nroj tsuag, cov kab sib dhos, thiab cov khoom lag luam. tuaj yeem txhawb nqa cov khoom sib zog ua haujlwm tau zoo thaum hloov mus rau ntau qhov chaw layouts.Nrog kev tsim kho yooj yim thiab kev siv ncaj qha, kev saib xyuas thiab tshuaj xyuas feem ntau yog yooj yim dua.





Cov Chaw Ua Haujlwm me me: Siv rau hauv cov chaw uas tsis muaj lub taub hau lossis qhov chaw kaw qhov chaw uas ib txwm ua haujlwm cranes tsis tuaj yeem nruab.

Lub teeb rau Nruab Nrab Lifting: Feem ntau siv rau cov khoom sib zog (feem ntau 1-10 tons) hauv kev tsim khoom, sib dhos, lossis kev saib xyuas.

Complex Workstations: Zoo tagnrho rau cov kab ntau lawm lossis cov chaw sib dhos uas xav tau kev txav mus los thiab nquag, me me thauj khoom.

Kev Thauj Mus Los Ntawm Chaw Ua Haujlwm: Tsim nyog rau kev txav cov khoom hla ntau lub chaw ua haujlwm hauv ib lub bay lossis lub tsev.

Indoor Warehouses: Feem ntau nyob rau hauv warehouses los yog factories nrog pre-existed ceilings, qhov twg cov crane khiav kab teeb tuaj yeem txuas ncaj qha.





Tsim thiab Engineering: Nkag siab txog cov neeg siv khoom xav tau, xws li lub peev xwm thauj khoom, ncua, nqa qhov siab, qhov chaw ua haujlwm, thiab txhua yam tshwj xeeb. Tsim kom ntxaws CAD kos duab ntawm lub crane qauv, nrog rau lub ntsiab girder, kawg carriages, thiab kev txhawb nqa systems.Txhim kho lub tshuab hluav taws xob (motors, controllers, wiring) thiab mechanical components (hoist, trolley, and drive mechanisms). Xyuas kom tus qauv tsim raws li cov qauv tsim nyog (xws li ASME, ISO, lossis cov qauv hauv cheeb tsam).

Khoom Siv Khoom: Txiav cov hlau qib siab rau lub ntsiab girder, kawg cov tsheb thauj khoom, thiab cov qauv kev txhawb nqa.Ua lub cev muaj zog, tswj vaj huam sib luag, thiab cov xaim hluav taws xob. Tau txais lub zog, lub log, hoists, thiab lwm yam khoom tseem ceeb.

Fabrication ntawm Cheebtsam: Hlau daim hlau thiab profiles raug txiav kom meej qhov ntev.Weld lub steel Cheebtsam los tsim lub girder thiab kawg carriages.Machine qhov chaw tseem ceeb rau kev sib raug zoo thiab haum ntawm qhov chaw. Sandblasting lossis txhaj tshuaj blasting yog ua, ua raws li kev pleev xim los yog galvanizing rau kev tiv thaiv corrosion.Semble lub hoisting mechanism thiab trolley tivthaiv.Pre-assemble Cheebtsam zoo li lub ntsiab girder, kawg carriages, thiab trolley nyob rau hauv seem.Raws lub trolley mus rau lub ntsiab girder thiab txuas. qhov kawg carriages.Nruab thiab txuas cov motors, tswj cov tshuab, thiab xaim rau cov khoom siv hluav taws xob.

Kev soj ntsuam zoo: Tshawb xyuas qhov ntev thiab kev ua kom zoo ntawm tag nrho cov khoom siv.Ua qhov ntsuas qhov hnyav los xyuas cov qauv kev ncaj ncees thiab kev ua haujlwm.Ua kom tag nrho cov tshuab hluav taws xob ua haujlwm kom raug, suav nrog kev nres thaum muaj xwm txheej ceev thiab txwv cov keyboards.Test lub crane txav raws txoj kev khiav thiab hoist ua haujlwm.

Disassembly thiab Ntim (yog tias xav tau): Rau kev thauj mus los, lub crane yuav raug txiav ib nrab thiab ntim kom ruaj ntseg rau kev xa khoom mus rau qhov chaw teeb tsa.

Kev teeb tsa thiab Kev Ua Haujlwm: Sib sau ua ke ntawm crane ntawm qhov chaw teeb tsa, suav nrog kev teeb tsa ntawm cov kab hluav taws xob khiav.Ua kom lub crane khiav zoo ntawm cov lem lossis khiav. Muab kev cob qhia kev ua haujlwm thiab kev nyab xeeb rau cov neeg siv kawg.

Kev Them Nqi thiab Kev Kho: Muab cov crane ua tiav nrog rau tag nrho cov ntaub ntawv tseem ceeb, suav nrog daim ntawv pov thawj kev kuaj xyuas, kev saib xyuas lub sijhawm, thiab phau ntawv ua haujlwm.Muab kev txhawb nqa tom qab muag, xws li kev saib xyuas tsis tu ncua thiab cov khoom seem.

Rhiav saib:

Lub tuam txhab tau teeb tsa cov cuab yeej ntse tswj kev tswj hwm lub platform, thiab tau teeb tsa 310 teeb (teev) ntawm kev tuav thiab vuam robots. Tom qab ua tiav ntawm txoj kev npaj, yuav muaj ntau tshaj 500 teeb (sets), thiab cov khoom siv sib txuas yuav ncav cuag 95%. 32 welding kab tau muab tso rau hauv kev siv, 50 tau npaj los nruab, thiab cov khoom siv hluav taws xob ntawm tag nrho cov kab khoom tau mus txog 85%.
