Beam Launching Gantry Crane

Lub Beam Launching Gantry Crane yog ib hom tshwj xeeb ntawm crane siv nyob rau hauv kev tsim kho kev lag luam rau kev sib dhos thiab tso rau precast qhob kab teeb los yog choj girders. Hom crane no yog qhov tseem ceeb rau kev txhim kho kom zoo thiab nyab xeeb ntawm cov kab hluav taws xob lossis girders hauv kev tsim cov choj, hla hla, thiab viaducts. Ntawm no yog ib qho khoom qhia qhia txog cov yam ntxwv tseem ceeb thiab kev ua haujlwm:









1.Heavy Lifting Peev Xwm:

• Tsim los tuav hnyav precast qhob kab teeb lossis choj girders.
• Lub peev xwm nqa tau raws li cov kev cai tshwj xeeb ntawm kev tsim kho choj.

2.Long Reach thiab Span:

• Nruab nrog ntev kab rov tav ncav cuag thiab ncua kom npog qhov dav ntawm tus choj lossis viaduct tau tsim.
• Adjustable ncua kom haum raws li tus choj dav dav.

3. Precise Positioning:

• Precise tswj systems kom raug qhov chaw ntawm kab teeb thaum lub sij hawm installation.
• Advanced automation nta rau kev ua haujlwm zoo thiab nyab xeeb.

4.Modular Tsim:

• Modular tsim rau kev thauj mus los yooj yim, sib dhos, thiab disassembly.
• Adaptability rau ntau qhov chaw tsim kho layouts.

5. Kev nyab xeeb nta:

• Kev nyab xeeb yog qhov tseem ceeb tshaj plaws nrog cov yam ntxwv xws li kev tiv thaiv overload, nres thaum muaj xwm txheej ceev, thiab cov khoom siv tiv thaiv kev sib tsoo.
• Tus neeg teb xov tooj cabins tsim los kom pom kev pom thiab tswj tau zoo.

6.High Efficiency:

• Kev sib dhos ceev thiab disassembly kom txo qis sijhawm.
• Fast thiab npaum beam installation, pab rau qhov project ncua sij hawm.

7. Kev txiav txim siab ib puag ncig:

• Lub zog-npaum tsim thiab kev ua haujlwm.
• Kev txo qis ntawm kev cuam tshuam ib puag ncig thaum tsim kho.

8.Customization Options:

• Kev xaiv rau customization raws li qhov project tshwj xeeb yuav tsum tau ua.
• Kev daws teeb meem rau ntau hom kev tsim kho choj.

9.Remote Control thiab Automation:

• Kev tswj chaw taws teeb muaj peev xwm txhim kho kev nyab xeeb thiab raug.
• Kev koom ua ke nrog automation systems rau kev ua haujlwm yooj yim.

10.Maintenance thiab Serviceability:

• Tsim kom yooj yim txij nkawm nrog cov khoom siv tau yooj yim.
• Kev txhawb nqa dav dav thiab kev pabcuam kev pabcuam rau kev tu ncua kev xav tau.







Lub Beam Launching Gantry Crane muaj ntau qhov chaw thiab cov khoom siv, txhua tus ua lub luag haujlwm tseem ceeb hauv crane tag nrho kev ua haujlwm. Nov yog cov ntsiab lus ntawm cov khoom tseem ceeb thiab cov khoom siv feem ntau pom hauv Beam Launching Gantry Crane:

• Main Girder:Lub ntsiab kab rov tav qauv uas spans lub dav ntawm tus choj los yog viaduct yog tsim. Nws txhawb nqa tag nrho qhov hnyav ntawm lub crane thiab lub thauj khoom raug nqa.
• End Carriages:Cov log tsheb uas nyob ntawm txhua qhov kawg ntawm lub ntsiab girder. Lawv nyob hauv lub crane lub cev muaj zog thiab lub log, tso cai rau kev txav mus los ntawm txoj kev.
• Vertical Support Legs:Cov qauv ntsug uas txuas qhov kawg carriages mus rau lub ntsiab girder, muab kev ruaj ntseg thiab kev txhawb nqa.
• Hoisting Mechanism:Lub luag hauj lwm rau lifting thiab txo cov precast qhob kab teeb. Nws muaj xws li lub hoist, hlau hlua, thiab ib tug nuv los yog lwm yam lifting txuas.
• Trolley:Lub mechanism uas txav horizontally raws lub ntsiab girder. Nws txhawb nqa lub hoisting mechanism thiab tso cai rau qhov tseeb qhov chaw ntawm lub load.
• Longitudinal Travel Mechanism:Lub kaw lus uas ua rau lub crane txav mus raws qhov ntev ntawm tus choj lossis viaduct. Nws feem ntau suav nrog lub cev muaj zog, lub log, thiab lub zog tswj.
• Cabins lossis Operator Control Chaw Nres:Cov cabins kaw lossis cov chaw tswj xyuas uas cov neeg ua haujlwm tswj hwm thiab tswj cov crane txav thiab ua haujlwm. Lawv muab qhov pom tseeb ntawm qhov chaw tsim kho.
• Hluav taws xob System:Cov khoom siv hluav taws xob, suav nrog cov cables, xaim, thiab tswj vaj huam sib luag, tsim nyog rau kev ua haujlwm ntawm crane. Nws suav nrog kev tswj hwm rau lub crane ntau yam haujlwm.
• Kev nyab xeeb nta:Ntau yam kev nyab xeeb xws li cov khoom siv tiv thaiv overload, khawm nres thaum muaj xwm ceev, thiab kev tiv thaiv kev sib tsoo kom ntseeg tau tias muaj kev nyab xeeb ntawm ob qho khoom siv thiab qhov chaw tsim kho.
• Automation thiab Control System:Lub kaw lus uas automates qee yam crane ua haujlwm thiab tso cai rau kev tswj chaw taws teeb. Nws suav nrog programmable logic controllers (PLCs) thiab lwm yam kev tswj xyuas kev sib tshuam.
• Counterweights:Ntxiv qhov hnyav ntxiv rau lub crane txhawm rau txhawm rau txhawm rau txhawm rau txhawm rau nqa, ua kom ruaj khov thiab tiv thaiv tipping.
• Rails lossis Tracks:Lub infrastructure uas lub crane txav. Nws muab txoj hauv kev coj mus rau qhov ntev mus ncig ntawm crane.
• Lifting Attachments:Tshwj xeeb txuas los yog hooks siv los ruaj ntseg thiab nqa precast qhob beams los yog choj girders.













Beam Launching Gantry Cranes muaj ntau yam zoo hauv kev tsim kho kev lag luam, tshwj xeeb tshaj yog nyob rau hauv kev sib dhos thiab tso rau ntawm precast qhob kab teeb lossis choj girders. Nov yog qee qhov txiaj ntsig tseem ceeb:



• Kev nyab xeeb ntxiv:Cov yam ntxwv kev nyab xeeb xws li cov khoom siv tiv thaiv kev sib tsoo, kev tiv thaiv overload, thiab lub tshuab nres thaum muaj xwm ceev txhim kho tag nrho cov chaw ua haujlwm kev nyab xeeb, txo qhov kev pheej hmoo ntawm kev sib tsoo thaum lub sijhawm ua haujlwm crane.
• Precise Positioning:Cov cranes tau nruab nrog cov kev tswj hwm qib siab uas tso cai rau qhov tseeb ntawm qhov precast qhob kab teeb, ua kom muaj kev sib raug zoo thaum lub sijhawm teeb tsa.
• Adaptability rau ntau qhov project:Beam Launching Gantry Cranes muaj ntau yam thiab tuaj yeem hloov kho kom haum rau ntau yam kev tsim kho choj nrog rau qhov sib txawv, qhov dav, thiab kev thauj khoom.
• Modular Design rau Mobility:Cov qauv tsim qauv ntawm cov cranes no tso cai rau kev thauj mus los yooj yim, sib dhos, thiab disassembly, ua rau lawv tsim nyog siv rau ntau qhov chaw tsim kho.
• High Lifting Capacity:Cov cranes no yog tsim los tswj hnyav precast qhob kab teeb, muab qhov tsim nyog nqa lub peev xwm rau kev tsim kho cov qauv choj ruaj khov thiab ruaj khov.
• Kev teeb tsa nrawm:Cov cranes no pab txhawb kev ceev thiab meej installation ntawm cov khoom siv choj, ua rau kom ua tiav qhov project sai thiab txo lub sijhawm tsim kho.
• Ntev Reach thiab Span:Nrog rau qhov ntev kab rov tav ncav cuag thiab ncua, cov cranes tuaj yeem npog tag nrho qhov dav ntawm tus choj lossis viaduct, txo qhov xav tau ntawm kev hloov pauv thaum siv.
• Chaw taws teeb tswj thiab Automation:Beam Launching Gantry Cranes feem ntau muaj peev xwm tswj tau cov chaw taws teeb, txhim kho kev nyab xeeb thiab tso cai rau cov neeg ua haujlwm tswj cov crane ntawm qhov chaw nyab xeeb. Automation nta ua rau muaj kev ua haujlwm zoo dua.
• Tus nqi tsim nyog:Los ntawm kev ua kom cov txheej txheem tsim kho thiab txo qis qis qis, cov cranes no tuaj yeem ua rau kev txuag nqi ntawm kev ua haujlwm thiab kev siv nyiaj tag nrho.
• Minimized Environmental Impact:Kev tsim hluav taws xob tsim hluav taws xob thiab muaj peev xwm ua kom tiav cov haujlwm tsim kho sai dua tuaj yeem ua rau txo qis hauv ib puag ncig cuam tshuam nrog kev tsim kho.
• Kev kho yooj yim:Cov qauv tsim thiab siv tau ntawm cov cranes no ua kom yooj yim txij nkawm, kom ntseeg tau tias cov cuab yeej tseem nyob hauv qhov kev pom zoo thoob plaws hauv nws lub neej ua haujlwm.









Beam Launching Gantry Cranes pom dav daim ntawv thov nyob rau hauv kev tsim kho kev lag luam, tshwj xeeb tshaj yog nyob rau hauv tej yaam num uas muaj kev sib dhos thiab muab tso rau ntawm precast qhob beams los yog choj girders. Lawv cov qauv tsim tshwj xeeb thiab muaj peev xwm ua rau lawv zoo haum rau ntau yam kev siv, suav nrog:



• Kev tsim kho choj:Beam Launching Gantry Cranes feem ntau yog siv rau hauv kev tsim cov choj, qhov twg cov kab teeb precast yuav tsum tau nqa, tso, thiab sib dhos nrog qhov tseeb. Lawv ua hauj lwm rau ob qho tib si kev loj thiab railway choj tej yaam num.
• Kev tsim kho Viaduct:Viaducts, uas yog elevated txoj kev los yog railway qauv, feem ntau yuav tsum tau lub installation ntawm ntev thiab hnyav girders. Beam Launching Gantry Cranes yog cov cuab yeej siv hauv kev sib dhos thiab kev tso chaw ntawm cov khoom no.
• Overpass Kev Tsim Kho:Nyob rau hauv kev tsim kho ntawm overpasses thiab flyovers, qhov chaw siab ntawm txoj kev hla mus rau lwm txoj kev los yog obstacles, cov cranes yog siv los nqa thiab nruab precast qhob kab teeb.
• Infrastructure Projects:Cov cranes no tau ua haujlwm nyob rau hauv ntau yam kev tsim kho vaj tse uas koom nrog kev tsim vaj tsev nrog cov khoom ua vaj tse precast, xws li cov neeg taug kev taug kev, culverts, thiab lwm yam kev ua haujlwm siab.
• Highway thiab Railway Projects:Beam Launching Gantry Cranes ua lub luag haujlwm tseem ceeb hauv txoj kev loj thiab kev tsim kho kev tsheb ciav hlau, ua kom muaj txiaj ntsig zoo thiab muaj kev nyab xeeb ntawm cov kab hluav taws xob precast rau overpasses, underpasses, thiab lwm yam qauv.
• Kev loj hlob hauv nroog:Hauv cov phiaj xwm kev loj hlob hauv nroog, cov cranes no yog siv rau kev tsim kho ntawm txoj kev siab, cov neeg taug kev txuas hniav, thiab lwm yam qauv uas yuav tsum tau ua kom tiav qhov chaw ntawm precast qhob Cheebtsam.
• Long-Span Choj Kev Tsim Kho:Rau kev tsim cov choj ntev, qhov ntev thiab qhov hnyav ntawm cov khoom siv ntawm tus choj yog qhov tseem ceeb, Beam Launching Gantry Cranes muab lub peev xwm nqa thiab ncav cuag qhov xav tau rau kev tsim kho kom zoo.
• Railway Infrastructure:Beam Launching Gantry Cranes tau ua haujlwm nyob rau hauv cov phiaj xwm kev tsheb ciav hlau, suav nrog kev tsim kho cov tsheb ciav hlau siab, cov choj hla kev tsheb ciav hlau, thiab lwm cov qauv hauv kev tsheb ciav hlau.
• Harbor thiab Port Infrastructure:Hauv kev tsim kho chaw nres nkoj thiab chaw nres nkoj, cov cranes no tuaj yeem siv rau kev tsim kho cov kev taug kev siab, chaw thau khoom, thiab lwm yam khoom siv uas yuav tsum tau muaj kev txhim kho ntawm cov khoom ua vaj tse precast.
• Customized Construction Projects:Kev hloov kho thiab kev hloov kho ntawm cov cranes no ua rau lawv tsim nyog rau ntau yam ntawm kev tsim kho cov haujlwm nrog cov kev xav tau tshwj xeeb, pab txhawb rau lawv cov kev paub ntau yam hauv thaj chaw.







Cov txheej txheem tsim khoom ntawm Beam Launching Gantry Crane suav nrog ntau theem, los ntawm kev tsim thiab tsim khoom mus rau kev sib dhos thiab kev sim. Nov yog ib qho kev piav qhia dav dav ntawm cov txheej txheem tsim khoom:



1. Tsim thiab Engineering:

• Kev Ntsuam Xyuas Txoj Haujlwm: Nkag siab txog cov kev xav tau tshwj xeeb ntawm qhov project, suav nrog qhov ntev ntawm tus choj, lub peev xwm thauj khoom, thiab ib puag ncig yam.
• Tus Qauv Tsim: Tsim cov qauv tsim ntawm lub gantry crane, nrog rau lub ntsiab girder, kawg carriages, txhawb ob txhais ceg, thiab lwm yam.
• Mechanical and Electrical Systems: Tsim lub tshuab hoisting, trolley, longitudinal travel system, hluav taws xob tswj, thiab kev nyab xeeb nta.

2. Kev yuav khoom:

• Raw Khoom: Tau txais cov ntaub ntawv zoo xws li hlau rau cov qauv tseem ceeb, tshwj xeeb alloys rau cov khoom tseem ceeb, cov khoom siv hluav taws xob, thiab lwm yam khoom siv.

3. Fabrication:

• Txiav thiab Shaping: Siv cov cuab yeej txiav qib siab los tsim cov khoom hlau raws li tus qauv tsim.
• Vuam: Sib sau cov khoom txiav los ntawm kev vuam, kom ntseeg tau qhov tseeb thiab kev ncaj ncees.
• Machining: Tshuab cov khoom tseem ceeb rau kev ua siab ntev rau kev ua haujlwm zoo.

4. Kev sib dhos:

• Main Girders thiab End Carriages: Sib sau lub ntsiab girder, kawg carriages, thiab txhawb ob txhais ceg los tsim cov qauv ntawm cov gantry crane.
• Mechanical Systems: Txhim kho lub hoisting mechanism, trolley, thiab longitudinal mus ncig teb chaws systems, kom ntseeg tau tias kev sib raug zoo thiab functionality.
• Cov Hluav Taws Xob Hluav Taws Xob: Kev sib xyaw cov khoom siv hluav taws xob, xaim hluav taws xob, thiab cov tswj vaj huam sib luag rau hauv crane tus qauv.

5. Kev sim:

• Kev Ntsuam Xyuas Kev Ua Haujlwm: Ua cov kev ntsuas kev ua haujlwm zoo ntawm cov tshuab thiab hluav taws xob kom ntseeg tau tias lawv ua haujlwm raws li cov qauv tsim.
• Load Testing: Ua cov kev xeem thauj khoom kom paub tseeb tias lub peev xwm nqa thiab kev ruaj ntseg ntawm crane nyob rau hauv cov xwm txheej sib txawv.
• Kev Ntsuam Xyuas Kev Nyab Xeeb: Ntsuas thiab ntsuas txhua yam kev nyab xeeb, suav nrog cov tshuab nres thaum muaj xwm txheej ceev, cov cuab yeej tiv thaiv kev sib tsoo, thiab kev tiv thaiv overload.

6. Painting thiab Txheej:

• Kev Kho Hniav: Siv cov tshuaj tiv thaiv thiab cov xim pleev xim kom tiv thaiv kev xeb thiab txhim kho lub crane lub zog, tshwj xeeb tshaj yog nyob rau hauv kev tsim kho sab nraum zoov.

7. Kev Tswj Xyuas Zoo:

• Kev tshuaj xyuas: Ua kom muaj kev tshuaj xyuas zoo ntawm txhua theem ntawm kev tsim khoom txhawm rau txheeb xyuas thiab daws cov teeb meem lossis kev sib txawv ntawm cov qauv tsim.

8. Cov ntaub ntawv:

• Phau Ntawv Qhia thiab Cov Ntaub Ntawv: Npaj cov ntawv ua haujlwm, phau ntawv qhia kev saib xyuas, thiab cov ntaub ntawv rau cov neeg siv kawg.

9. Kev xa khoom thiab kev teeb tsa:

• Kev thauj mus los: Disassemble lub crane yog tias tsim nyog thiab npaj kev thauj mus los rau qhov chaw tsim kho.
• Kev teeb tsa: Rov ua dua lub crane ntawm qhov chaw, ua kom muaj kev sib raug zoo thiab ua raws li cov qauv kev nyab xeeb.

10. Kev Ua Haujlwm:

• Kev Tshawb Fawb Kev Ua Haujlwm: Ua qhov kev kuaj xyuas ua haujlwm kawg kom ntseeg tau tias txhua yam khoom siv ua haujlwm sib txuam ua ke.
• Kev cob qhia: Muab kev cob qhia rau cov neeg ua haujlwm thiab cov neeg ua haujlwm saib xyuas kev nyab xeeb thiab siv tau zoo ntawm Beam Launching Gantry Crane.

11. Kev tu thiab kev txhawb nqa:

• Kev them nyiaj yug Post-Installation: Tsim kom muaj kev tu ncua, kev txhawb nqa, thiab kev daws teeb meem raws li xav tau.







Henan Mine Crane Co., Ltd tau siv cov cuab yeej ntse tswj kev lag luam thiab xa tawm 310 txheej ntawm kev tuav thiab vuam neeg hlau. Raws li kev ua tiav ntawm qhov pib, tag nrho cov teeb tsa yuav dhau 500, ua tiav 95% cov khoom siv sib txuas. Tam sim no, 32 welding kab yog ua haujlwm, nrog rau kev npaj rau nruab ib qho ntxiv 50. Tus nqi automation tag nrho rau tag nrho cov khoom kab tau mus txog 85%.
